PAX S300 WITH CORNERSTORE GUIDE
Note: The PAX must first be set up on your network. An ethernet cable will be required to hardwire the
PAX to your network router. You will use the
ethernet cable.
Obtaining the IP Address for input into Cornerstore POS
RED
dongle on attached to the PAX device to connect the
1. Press the blue FUNC button and the 1 key at
the same time.

Advertisement

loading
Need help?

Need help?

Do you have a question about the S300 and is the answer not in the manual?

Questions and answers

Related Manuals for PAX S300

Summary of Contents for PAX S300

  • Page 1 PAX S300 WITH CORNERSTORE GUIDE Note: The PAX must first be set up on your network. An ethernet cable will be required to hardwire the PAX to your network router. You will use the dongle on attached to the PAX device to connect the ethernet cable.
  • Page 2 2. Enter the default password “916860” then press the green key on the key pad. If the default password does not work, you will need to contact your payment processor for assistance. 3. Tap on the down arrow to access additional selections.
  • Page 3 4. Tap on Communication or press 2 on the keypad. 5. Enter the default password “916860” then press the green key on the key pad. If the default password does not work, you will need to contact your payment processor for assistance.
  • Page 4 6. Tap on the down arrow to access additional selections. 7. Tap on LAN Parameters or press 3 on the keypad.
  • Page 5 8. Tap on IP Address or press 2 on the keypad. 9. Make a note of the IP Address that is displayed in the box. We will need to enter this information into CRE later on. Tap twice on the blue arrow on the screen or press the red button with the X twice to go back to the previous menu.
  • Page 6 10. Tap on LAN Type or press 1 on the keypad. 11. Tap on Static or press 2 on the keypad.
  • Page 7 12. Tap on IP Address or press 2 on the keypad. 13. Confirm the IP Address displayed is the same as what you noted in step 9. Alternatively, you may assign a different IP address by tapping on the blue arrow once or pressing the red key with the X, then using the number pad to enter a new IP address;...
  • Page 8 HEARTLAND. Then, enter the IP Address found on the PAX from the previous section. Enter “10009” for the port number and click save and exit. Ring up a test credit sale. You should now see your sale rung up on the PAX.
