Adjusting Solenoid 1 To Change Quintic Speed - Polaroid Spectra/Image One Board Repair Manual

Hide thumbs
Table of Contents

Advertisement

To increase Quintic speed,
turn screw CCW
To decrease Quintic speed,
turn screw CW
Solenoid 1
Adjusting Screw
Figure 3-20. Adjusting solenoid 1 to change quintic speed
58
