- Page 1 Screen Mount Kit Accessory Mounts © 2013 Martin Professional A/S...
- Page 2 © 2013 Ma rtin Professiona l A/S. Informa tion subject to cha nge w ithout notice. Ma rtin Professiona l A/S a nd a ll a ffilia ted compa nies discla im lia bility for a ny injury, da ma ge, direct or indirect loss, consequentia l or economic loss or a ny other loss occa sioned by the use of, ina bility to use or relia nce on the informa tion conta ined in this ma nua l.
- Page 3 1. Martin M6 screen mount kit, PN 91613109 Included items: console bracket, screen bracket, 4 screws, cable 2. Manfrotto Magic Arm 244N http://www.manfrotto.com/variable-friction-arm 3. Martin M-Series Touch Screen Module PN 91613108 (or other VESA compatible screen) M-Series 3.0 © 2013 Martin Professional A/S...
- Page 4 To mount a screen place it on a flat surface. Position the thumbwheel sideways and attach the screen bracket with the supplied allen screws to the back of the screen and fasten them tightly. M-Series 3.0 © 2013 Martin Professional A/S...
- Page 5 Next, attach the console bracket to the side of the console just under the carrying handle and screw down the thumbwheel for a tight fit. The feet of the bracket have to be supported by the same flat and even surface the console is standing on. M-Series 3.0 © 2013 Martin Professional A/S...
- Page 6 Lastly, connect the 10-pin power plug to the screen, then to the desk. Power up the console and confirm proper operation. The dimensions of the external screen may have to adjusted set using the Display Settings menu in the M6. M-Series 3.0 © 2013 Martin Professional A/S...
- Page 7 The maximum depth of the screw is 10mm, or 3/8 of an inch. Each side has three support points Examples The provides links are suggestions where to find such accessories. Martin is not associated with these companies. Any arms and holders utilizing the 1/4"-20 thread will work. Some items may not be available in all countries.
- Page 8 Paperclip or Camera Camera Arm M-Series 3.0 © 2013 Martin Professional A/S...
- Page 9 1" Ball with 1/4"-20 post 4" Arm Once a 1" ball is attached to the desk, anything from RAM Mount can be used. Here are some basic examples: Drink Holder or Ashtray Tablets and iPad Clipboard Case M-Series 3.0 © 2013 Martin Professional A/S...
- Page 10 • Olof Palmes Allè 18 • 8200 Aarhus N • Denmark Tel: +45 8740 000 • Fax +45 8740 0010...
