This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz. Power Linking You can link up to 7 Ovation F-265WW products at 120 V, 12 products at 208 V, or 13 products at 230 V. Never exceed this number. Power linking cords can be purchased separately.
Remove blown fuse and replace with a good fuse of the same type and rating. Screw the fuse holder cap back in place and reconnect power. DMX Linking The Ovation F-265WW will work with a DMX controller using a 3- or 5-pin DMX data connection. A DMX Primer is available from www.chauvetprofessional.com. DMX Connection The Ovation F-265WW uses a 3- or 5-pin DMX data connection for its DMX personalities: 1Ch: 8bit Dim, 2Ch: 16bit Dim, 2Ch: 8bit Dim+Zoom, and 5Ch: 16bit-Full.
Shows total hours the product has been powered on Information Version <V_._> Shows current firmware version <_ _ _ _ _ _ _ _> Shows product UID Reset Resets the product to factory default settings Factory Ovation F-265WW QRG Rev. 2...
2Ch: 8bit Dim+Zoom Channel Function Value Percent/Setting Dimmer 0–100% Zoom 0–100% 2Ch: 16bit Dim Channel Function Value Percent/Setting Dimmer 0–100% Dimmer Fine 0–100% 1Ch: 8bit Dim Channel Function Value Percent/Setting Dimmer 0–100% Ovation F-265WW QRG Rev. 2...
100–240 VCA, 50/60 Hz. Alimentación en Cadena Puede enlazar hasta 7 productos Ovation F-265WW a 120 V, 12 productos a 208 V o 13 productos a 230 V. Los cables de alimentación en cadena se pueden adquirir por separado.
Conexión DMX El Ovation F-265WW usa una conexión de datos DMX normal para sus personalidades DMX: 1Ch: 8bit Dim, 2Ch: 16bit Dim, 2Ch: 8bit Dim+Zoom, y 5Ch: 16bit-Full. Vea el Manual de usuario para conectar y configurar para funcionamiento Conexión Maestro/Esclavo...
Muestra el nombre total de las horas del producto Information Version <V_._> Muestra instalada la versión de firmware <_ _ _ _ _ _ _ _> Muestra el UID # del producto Reset Factory Reinicia a la configuración de fábrica Ovation F-265WW GRR Rev. 2...
Page 9
2Ch: 8bit Dim+Zoom Canal Función Valor Porcentaje/Configuración Atenuador 0–100% Zoom 0–100% 2Ch: 16bit Dim Canal Función Valor Porcentaje/Configuración Atenuador 0–100% Atenuador fino 0–100% 1Ch: 8bit Dim Canal Función Valor Porcentaje/Configuración Atenuador 0–100% Ovation F-265WW GRR Rev. 2...
MANUEL DE RÉFÉRENCE À Propos de ce Manuel Le Manuel de Référence (MdR) Ovation F-265WW reprend des informations de base sur ce produit notamment en matière de connexions, montage, options de menu et valeurs DMX. Téléchargez le manuel d'utilisation sur www.chauvetprofessional.com...
Ce produit est doté d'une alimentation universelle prenant en charge toute tension d'entrée comprise entre 100 et 240 VCA, 50/60 Hz. Connexion Électrique Vous pouvez connecter jusqu’à 7 Ovation F-265WW à 120 V, 12 unités à 208 V ou 13 unités à 230 V. Vous pouvez vous procurer séparément des cordons d'alimentation. Prise CA Connexion Câble (États-Unis)
Permet de parcourir les listes de menu vers le bas, dans une fonction permet de diminuer les <DOWN> valeurs numériques <KNOB1> Appuyez puis tournez pour augmenter ou diminuer le gradateur <KNOB2> Appuyez puis tournez pour augmenter ou diminuer le zoom Ovation F-265WW MdR Rév. 2...
Page 13
Affiche le nombre total des heures du produit Information Version <V_._> Affiche la version du logiciel installée <_ _ _ _ _ _ _ _> Affiche UID actuel Reset Factory Permet de réinitialiser aux valeurs par défaut d'usine Ovation F-265WW MdR Rév. 2...
Page 14
2Ch: 8bit Dim+Zoom Canal Fonction Valeur Pourcentage/Configuration Gradateur 0–100% Zoom 0–100% 2Ch: 16bit Dim Canal Fonction Valeur Pourcentage/Configuration Gradateur 0–100% Gradateur fin 0–100% 1Ch: 8bit Dim Canal Fonction Valeur Pourcentage/Configuration Gradateur 0–100% Ovation F-265WW MdR Rév. 2...
BEKNOPTE HANDLEIDING Over deze handleiding De Ovation F-265WW Beknopte Handleiding (BH) bevat basisinformatie over het product, zoals aansluiting, montage, menu-opties en DMX-waarden. Download de gebruikershandleiding op www.chauvetprofessional.com voor meer informatie. Disclaimer De informatie en specificaties in deze BH kunnen zonder voorafgaande kennisgeving worden gewijzigd.
Page 16
Dit product heeft een voeding met automatisch bereik die werkt met een ingangsspanning van 100–240 VAC, 50/60 Hz. Power Linking U kunt tot 7 Ovation F-265WW-producten koppelen bij 120 V, 12 producten bij 208 V of 13 producten bij 230 V. Dit aantal niet overschrijden. Power Linking-snoeren kunnen apart aangeschaft worden.
Navigeert omlaag via het menu of verlaagt de numerieke waarde wanneer in een functie <KNOB1> Eerst indrukken en daarna draaien om de dimmer te verhogen of te verlagen <KNOB2> Eerst indrukken en daarna draaien om de zoom te verhogen of te verlagen Ovation F-265WW BH Rev. 2...
Page 18
Fixture Hours <_ _ _ _H> Toont het totale aantal producturen Information Version <V_._> Toont de geïnstalleerde softwareversie <_ _ _ _ _ _ _ _> Geeft de huidige UID Reset Herstellen naar de fabrieksstandaard Factory Ovation F-265WW BH Rev. 2...
Voice: +52 (728) 690-2010 Outside the U.S., United Kingdom, Ireland, Mexico or Benelux, contact the dealer of record. Follow the instructions to request support or to return a product. Visit our website for contact details. Ovation F-265WW QRG Rev. 2...
