STM-1 mapping

1.4.10 Evaluation of Section Overhead (SOH) and VC-4/VC-3 Path Overhead (POH)

Display

of complete SOH and POH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . hexadecimal

of Trace Identifier J0, J1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ASCII, plain text

Evaluation

Bit error measurement

using PRBS 11 (bytes). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E1, F1, E2, F2

using PRBS 11 (byte groups) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D1 to D3, D4 to D12

Output

as bytes via DCC/ECC interface (V.11) . . . . . . . . . . . . . . . . . . . . . . . . . . E1, F1, E2, F2, K3, N1

as byte groups via DCC/ECC interface (V.11). . . . . . . . . . . . . . . D1 to D3, D4 to D12, K1 to K2

S-14

ANT-20/ANT-20E

Specifications
