Error Insertion (Anomalies; Error Measurement (Anomalies; Alarm Detection (Defects - Wavetek ANT-20 Operating Manual

ANT-20/ANT-20E
5.3

Error insertion (anomalies)

Trigger modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Single or Rate
Error type, anomaly
FAS
EM (BIP-8)
REI
Table S-8
5.4

Error measurement (anomalies)

The following anomalies can be evaluated and displayed in addition to the error types available
in the Mainframe.
Anomaly
FAS
EM (BIP-8)
REI
Table S-9
5.5

Alarm detection (defects)

The following defects can be evaluated and displayed in addition to the alarm types available in
the Mainframe.
Defect
AIS
LOF
RDI
UNEQ
PLM
TIM
Table S-10
Specifications
Available error types (anomalies) and trigger modes
LED indication of possible anomalies
LED indication of possible defects
Single
Yes
Yes
Yes
LED
FAS
B1/B2
-
LED
AIS
LOF/OOF
RDI
HP-UNEQ
HP-PLM
-
ATM Mappings
Rate
2E-3 to 1E-8
2E-3 to 1E-10
2E-4 to 1E-10
S-7
