Alarm generation (defects)

The following alarm types (defects) can be generated:
Defect
AIS_DS3
IDLE_DS3
LOF_DS3
YELLOW_DS3 (RDI)
PLCP_LOF
PLCP_RAI
Table S-11
7.1.3 Error insertion (anomalies)
Trigger types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Single error, error rate
Error type, anomaly
FE_DS3
Parity_DS3
FEBE_DS3
PLCP_FAS
PLCP_B1
PLCP_REI(FEBE)
Table S-12
S-10
Sensor function test
on/off
yes
yes
yes
yes
yes
yes
Available alarm types (defects)
Single
yes
yes
yes
yes
yes
yes
Available error types (anomalies) and trigger types
Sensor thresholds
M in N
-
-
-
-
M = 1 to N-1;
N = 1 to 8000
Rate
-
-
-
1E-3 to 1E-7
1E-3 to 1E-8
1E-3 to 1E-8
