ANT-20/ANT-20E
7.1.4 Error measurement (anomalies)
The following error types can be displayed and evaluated in addition to the error types provided
by the Mainframe.
Anomaly
FE_DS3, MFE_DS3
P_DS3, CP_DS3
FEBE_DS3
PLCP_FAS
PLCP_B1
PLCP_REI (FEBE)
Table S-13
7.1.5 Alarm detection (defects)
The following alarms can be displayed and evaluated in addition to the defects provided by the
Mainframe.
Defect
AIS_DS3
LOF_DS3, OOF_DS3
YELLOW_DS3
IDLE_DS3
PLCP_LOF
PLCP_RAI
Table S-14
Specifications
LED
FAS/CRC
-
-
FAS/CRC
B1/B2
-
LED display of possible anomalies
LED
AIS
LOF/LCD
RDI
-
LOF/LCD
-
LED display of possible defects
ATM Mappings
S-11
