Turin LED Ceiling Fan
model no. 052-6972
model no. 052-6972-6
Instruction Manual
Toll-free: 1-866-827-4985
IMPORTANT: Please read and understand this manual before any assembly. Before
beginning assembly of product, make sure all parts are present. Compare parts
with exploded view. If any part is missing, or if you have any questions, contact
customer service at 1-866-827-4985 (toll-free).
V. 3 2016
Advertisement
Table of Contents
Related Manuals for NOMA 052-6972-6
Summary of Contents for NOMA 052-6972-6
- Page 1 Turin LED Ceiling Fan model no. 052-6972 model no. 052-6972-6 Instruction Manual Toll-free: 1-866-827-4985 IMPORTANT: Please read and understand this manual before any assembly. Before beginning assembly of product, make sure all parts are present. Compare parts with exploded view. If any part is missing, or if you have any questions, contact customer service at 1-866-827-4985 (toll-free).
-
Page 2: Table Of Contents
Toll-free: 1-866-827-4985 · model no. 052-6972-6 Exploded view ......................... 1 Important safety instructions ..................2 Rules for safe installation .................... 2 Tools required for assembly ..................3 Assembly ........................... 3 Operation .......................... 7 Maintenance ........................8 Care and cleaning ......................8 Troubleshooting ...................... -
Page 3: Exploded View
EXPLODED VIEW Description Qty. Description Qty. Downrod Parts Pack Canopy Balance Pack Screw Cover Housing Fan Blade Fan Assembly Light Kit LED Lamp Mounting Bracket Remote Control Receiver Glass Shade... -
Page 4: Important Safety Instructions
Toll-free: 1-866-827-4985 • model no. 052-6972-6 IMPORTANT SAFETY INSTRUCTIONS Please retain this manual for future reference. Note: · A dry dust cloth is suitable for most cleanings. · Should the ceiling fan become wet, have a qualified electrician inspect it before next use. -
Page 5: Tools Required For Assembly
TOOLS REQUIRED FOR ASSEMBLY This manual is designed to make it as easy as possible for you to assemble, install, operate and maintain the ceiling fan. The following tools listed are required for assembly and installation: 1 x stepladder 1 x star-head screwdriver 1 x flat screwdriver 1 x wire stripper/pliers 1 x electrical tape... - Page 6 Toll-free: 1-866-827-4985 • model n o. 052-6972-6 ASSEMBLY Installation 1. Mounting bracket Note: The mounting bracket depicted will vary depending on the model . . Remove the four sets of side screws from mounting bracket and save for future use.
- Page 7 ASSEMBLY 3. Wiring instructions IMPORTANT: If you are not sure if the electrical outlet box and fan are grounded, contact a licensed electrician for advice. They must be grounded for safe operation. WARNING: before wiring. Remote and Receiver Pairing Codes are set by pushing the location of the dip switches located on the transmitter and receiver up or down.
-
Page 8: Toll-Free: 1-866-827-4985 · Model No. 052
Toll-free: 1-866-827-4985 • model no. 052-6972-6 ASSEMBLY · When wires are matched up, connect them by twisting frayed ends together (see Fig. 8a). · Screw wire connectors (3 are provided) onto the tops of the twisted wires (see Fig. 8b). -
Page 9: Operation
OPERATION Install the 9 V battery (included). To prevent damage to transmitter remove the battery if not used for long periods . · Restore power to ceiling fan and test for proper operation. · The fan remote control controls the fan settings: LIGHT DIMMER ON/OFF... -
Page 10: Maintenance
Toll-free: 1-866-827-4985 • model no. 052-6972-6 MAINTENANCE · Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets and blade attachments twice a year. Make sure they are secure. · There is no need to oil your fan. The motor has permanently-lubricated bearings. -
Page 11: Environmental Protection
TROUBLESHOOTING Problem Solution Possible reason Light does · Wires are not properly connected. · Ensure wire connector in switch not work housing is connected. · Light bulbs are faulty. · Unscrew light bulbs and discard properly. · This fan is equipped with a 190 W ·... -
Page 12: Warranty
Toll-free: 1-866-827-4985 • model no. 052-6972-6 WARRANTY This Noma product carries a limited ten (10) year warranty against defects in the motor, and a one (1) year warranty against defects in workmanship and materials. Noma Canada agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase.
