Appendix B: Remote Communication

Acquisition Mode and Miscellaneous Settings

Characters 9 and 10 of the front panel setup string define the remain
ing settings not defined by the other 8 characters. Table A 6 shows
setup state controlled by each bit. The only two bit setting is for
Acquisition MODE.
The last two characters of our example setup string are 1 and 2. The
bit values for these are 0001 and 0010, respectively. The decoding for
the bit values of character 9 is then the following:
H TIME OUT is enabled
H CH2 is selected to respond to the controls settings
H It is not a recalled waveform
H It is a valid store
Character 10 (0010) decodes as follows:
H The Acquisition MODE (2 bits) is NORM
H It is in STORE mode
H AUTO TRIGGER is not enabled
A 26
Appendices
