H DAC <DAC code>: <DAC value>;
This command sets a DAC value. A DAC is a digital to analog
converters for digitized potentiometer settings. The digital to ana
log converters determine the variable control settings for the
POSITION controls (horizontal and vertical), the trigger LEVEL
settings (CH1, CH2, and EXT), and the variable vertical gain (CH1
and CH2). See Table A 2 for the DAC code and DAC value data.
A 16
Table A 1: BUT Button Codes (Cont.)
Simulated Button Press
Menu Item 2
Menu Item 3
OFF
Trigger SOURCE
Trigger MODE
Trigger SLOPE
CH 2 Select
Ch1 Select
AUTO SETUP
Front Panel Setup Menu
Trigger Position Menu
Auxiliary Function Menu
Display Mode Menu
Save Waveform Menu
Recall Waveform Menu
STORE/NONSTORE
Acquisition Mode Menu
X10 MAG
Variable Gain
AUTO LVL: PUSH
