Paper Tray
3. Feed the paper into the Paper Loading Slot and release it once the motor engages and the printer
takes hold of the paper.
The printer automatically pulls through a form or two, leaving it registered at the top of a form.
4. Remove any excess ticket(s) from the printer.

Feeding Paper

The printer is designed to run with black mark indexed paper.
Use the FEED button to feed paper into printer. Press the FEED button to advance the paper to the
top of the next form.

Performing a Self Test

Press the FEED button during power up or reset to run a self test. This self test prints a
configuration ticket if the test passes successfully. The test ticket (illustrated in Figure 2-4) contains
important information on how the unit is configured.
© 2006 – 2007 FutureLogic, Incorporated. All Rights Reserved.
Figure 2-2
Paper
Loading
Slot
Figure 2-3 Feed Paper into Paper Loading Slot
Load a Paper Stack
Operators and Technicians Manual
Black Index
Mark
