1 Product Overview

Introduction

Each GEN2 Universal™ printer is an advanced thermal printer capable of creating high quality
complex output with a minimum of development and effort on the part of the user. The printer
module supports both serial and a Netplex current loop interface to allow operation in any
standard slot machine on the market.
Note: While PSA-66-ST2 refers to all models of the printer, the content of this manual is
primarily for the Netplex/USB interface of the GEN2 Universal printer (PSA-66-ST2NU). For
additional information on the Netplex and USB interfaces, please contact IGT.
Features of the GEN2 Universal printer include:
•
The ITH™ (Intelligent Ticket Handling) technology which prevents player interference with
any part of ticket production or presentation
•
May be mounted on an angle or horizontally
•
Simple paper loading—no loose parts
•
Variable paper capacity with different paper trays—300, 600, and 900 ticket trays
•
Windows® ticket/receipt development package via the TCL™ Editor utility
•
Page mode printing with TCL printer language
•
Line printer capability
•
High quality laser-like san serif fonts in multiple sizes
•
Advanced graphics printing
•
Windows connectivity
•
3 inch per second print speed
•
Wide temperature range operation
•
Standard and customized serial interfaces available—Netplex and USB
Additionally, a key feature of the GEN2 Universal printer is Universal Communications:
•
USB 2.0 Full Speed (Future GSA Compliant, IGT Compliant)
•
Netplex Port (Backward Compatible)

Warranty Information

Each printer has a two-year warranty as per the manufacturer's written warranty.
