5
Approved Antennas
Only approved antennas may be used in conjunction with AP822 access points. Access
Points have been designed to operate with the antennas listed below. Antennas not included
in this list are strictly prohibited for use with these devices. The required antenna impedance
is 50 ohms.
TABLE 5: Approved Antennas
Meru Part Numbers
ANT-ABGN23O-W
ANT-ABGN47O
ANT-O4ABGN-0606-O
ANT-I2ABGN-0304-O
ANT-O4ABGN-0607-
PT
ANT-ABGN-0406-W
Gain
2/3 dBi
Dual band Omni-directional dipole antenna
4.7/4.7 dBi
Dual band high gain dipole Omni directional
antenna
6/6 dBi
Dual band Omni directional 4-lead antenna
3/4 dBi
Dual band ceiling mount Omni directional 2-
lead antenna
6/7 dBi
Dual band wall mount patch 4-lead antenna
4/6dBi
Dual band Omni-directional antenna single
feed
Description
39
