The accessory required for such installation is listed below:
Stands (Optional)

Vertically on a Wall

Installation
The AP822 ships with a metal bracket (650-00234) that can be used for wall mounting. This
bracket is used in conjunction with the plastic 15/16" T-Bar Adapter/Wall Mount bracket (650-
00232) that easily locks the AP into place.
The accessory required for such installation is listed below:
15/16" T-bar & wall-mount combo
adapter (650-00232)
Wall-mount bracket (650-00234)
Wall-mount hardware kit (4 spac-
ers, M3x10 & M3x30 screws)
(840-00126)
User should bench test this mounting hardware in order to familiarize with the locking
1.
mechanism prior to actual installation.
Determine the desired location for mounting.
2.
Use the wall mount bracket as a template for screw holes and cable cutout.
3.
•
•
Place the metal bracket against the wall. It should be oriented such that the indicator text
4.
for wall-mounting is pointing upwards.
Attach the bracket to the wall using screws at the appropriate screw locations as indicated
5.
in
22
Item
Item
User may need to cut a hole in the wall or ceiling in the cable cutout area in order to hide
the cables during installation.
User may also use the optional RJ45 cable extension (840-00124 CBL-RJ45-ADAPT-
X5, comes in a 5 pack), if user do not want to cut a hole in the wall or ceiling.
"AP822 Wall Bracket" on page
Model Number
MNT-FEET-SET-X5
Model Number
23. Recommend #6, #8 (M3, M3.5).
Quantity
1 (set)
Quantity
1
1
1
