What Kind of Optimization Is Being Performed?
3.8.8

Branch Optimizations and Control-Flow Simplification

Example 3−4. Copy Propagation and Control-Flow Simplification
TMS320C2x/C2xx/C5x C Compiler Output:
_fsm:
*
* AR5 assigned to variable 'input'
*
L2:
L4:
L5:
L6:
EPI0_1:
The switch statement and the state variable from this simple finite state machine example
are optimized completely away, leaving a streamlined series of conditional branches.
3-20
The compiler analyzes the branching behavior of a program and rearranges
the linear sequences of operations (basic blocks) to remove branches or
redundant conditions. Unreachable code is deleted, branches to branches are
bypassed, and conditional branches over unconditional branches are simpli-
fied to a single conditional branch. When the value of a condition can be deter-
mined at compile time (through copy propagation or other data flow analysis),
a conditional branch can be deleted. Switch case lists are analyzed in the
same way as conditional branches and are sometimes eliminated entirely.
Some simple control-flow constructs can be reduced to conditional instruc-
tions, totally eliminating the need for branches. See Example 3−4.
fsm()
{
enum { ALPHA, BETA, GAMMA, OMEGA } state = ALPHA;
int *input;
while (state != OMEGA)
switch (state)
{
case ALPHA: state = ( *input++ == 0 ) ? BETA:
case BETA : state = ( *input++ == 0 ) ? GAMMA: ALPHA; break;
case GAMMA: state = ( *input++ == 0 ) ? GAMMA: OMEGA; break;
}
}
. . .
LAC *+ ; initial state == ALPHA
BNZ L5 ; if (input != 0) go to state GAMMA
LAC *+ ; state == BETA
BZ L4 ; if (input == 0) go to state GAMMA
LAC *+ ; state == ALPHA
BZ L2 ; if (input == 0) go to state BETA
B L5 ; else
LAC *+ ; state == GAMMA
BNZ EPI0_1 ; if (input != 0) go to state OMEGA
LARP AR5
LAC *+ ; state = GAMMA
BZ L6 ; if (input == 0) go to state GAMMA
; state == OMEGA
. . .
GAMMA; break;
go to state GAMMA
