Summary of Contents for Cognex DataMan 50
- Page 1 ® DataMan Quick Reference Guide 04/18/2017 Version:5.7.0.102...
- Page 2 Precautions Observe these precautions when installing the Cognex product, to reduce the risk of injury or equipment damage: To reduce the risk of damage or malfunction due to over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply, route all cables and wires away from high-voltage power sources.
-
Page 3: Product Overview
Product Overview Status LEDs: - Power: YELLOW = Power ON - Communication: Flashing YELLOW - Good / bad read: GREEN = good read / RED = bad read - Error: RED = error, check device log Cable Internal illumination 3-position M12 lens LED aimer Mounting holes (M3 x 3.5 mm) Remove side cover to access square nut (M3) -
Page 4: Dataman 50 Accessories
DataMan 50 Accessories CABLES USB Cable, 1.5 m (DM100-USB-000), USB Cable, 3 m (DM100-USB-030) USB and Flying Leads I/O Cable, 2.0 m (DM-USBIO-00) RS-232 and Flying Leads I/O Cable, 2.5 m (DM-RS232IO-00) RS-232 Cable, 1.5 m (DM100-RS232-000), Extension Cable, 5 m (DM100-EXTCBL-000) - Page 5 Dimensions...
-
Page 6: Field Of View And Reading Distances
Field of View and Reading Distances... -
Page 7: Connecting The Reader
Connecting the Reader... -
Page 8: Installation
Note: Cables are sold separately. If any of the standard components appear to be missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. CAUTION: All cable connectors are “keyed” to fit the connectors on the reader;... -
Page 9: Connect The Breakout Cable
Connect the Breakout Cable Note: Unused wires can be clipped short or tied back using a tie made of non- conductive material. For RS-232, use the Power Supply return path for ground. 1. Verify that the power supply being used is unplugged and not receiving power. -
Page 10: Install Software And Documentation And Connect The Reader
1. Connect the USB or RS-232 cable to your reader. 2. Connect the cable to a power supply. To configure a DataMan 50 reader, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site: http://www.cognex.com/support/dataman. -
Page 11: Dataman 50 Specifications
DataMan 50 Specifications 76 g (including cable) Weight Operating 0 ºC — 40 ºC (32 ºF — 104 ºF) Temperature Storage Temperature -10 ºC — 60 ºC (-14 ºF — 140 ºF) Maximum Humidity 95% (non-condensing) IP65 if sealing is installed properly... -
Page 12: Dataman 50 Imager Specifications
DataMan 50 Imager Specifications Specification DataMan 50 Series Imager Image Sensor 1/3 inch CMOS Image Sensor Properties 4.51 mm x 2.88 mm (H x V), 6.0 µm square pixels Image Resolution (pixels) 752 x 480 Electronic Shutter Speed 18 µs to 25 ms exposure... -
Page 13: Compliance Statements
2014/30/EU Electromagnetic Compatibility. For further information please contact: Cognex Corporation, One Vision Drive Natick, MA 01760 USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked. -
Page 14: Led Safety Statement
Exempt Risk Group. No further labeling is required. For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). - Page 15 In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a sound way. The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal.
-
Page 16: China Rohs
China RoHS Hazardous Substances 有 害 物 质 Part Name Lead (Pb) Mercury Cadmium Hexavalent Polybrominated Polybrominated 部 件 名 称 铅 (Hg) (Cd) Chromium biphenyls (PBB) diphenyl ethers 汞 镉 多 溴 联 苯 (Cr (VI)) (PBDE) 六 价 铬 多... - Page 17 Copyright © 2017 Cognex Corporation. All Rights Reserved.
