- Page 1 ® DataMan Quick Reference Guide 04/13/2017 Version:5.7.0.42...
- Page 2 Precautions Observe these precautions when installing the Cognex product, to reduce the risk of injury or equipment damage: To reduce the risk of damage or malfunction due to over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply, route all cables and wires away from high-voltage power sources.
-
Page 3: Product Overview
Product Overview External illumination mounting point Mounting holes (M3 x 5mm) Trigger button Power Train status Good/bad read Network Error Tuning button Peak meter Synchronized Acquisition RS-232 External light control Ethernet Power I/O... -
Page 4: Dataman 503 Accessories
External light cable (CCB-M12x4MS-xxx) (xxx specifies length) I/O extension cable, 5m straight (CKR-200-CBL-EXT) RS-232 M8 to SUB-D cable (CCB-M8X4-xx) Synchronization Cable (DM503-SYNC-012 - 1.2 meter, DM503-SYNC-05 - 5 meter) Xpand 15 (DMA-FOVE-15) Xpand 25 (DMA-FOVE-25) SVL Light Bar (IVSL-YLW300-xxx) - Page 5 Dimensions...
-
Page 6: Field Of View And Reading Distances
Field of View and Reading Distances... -
Page 8: Connecting The Reader
Connecting the Reader... -
Page 9: Installation
Note: Cables are sold separately. If any of the standard components appear to be missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. CAUTION: All cable connectors are "keyed" to fit the connectors on the... -
Page 10: Install Software And Documentation And Connect The Reader
To configure a DataMan 503 reader, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site: http://www.cognex.com/support/dataman. 1. After installing the software, connect the DataMan 503reader to your PC. -
Page 11: Dataman 503 Specifications
DataMan 503 Specifications Weight 1602 g Operating 0ºC — 45ºC (32ºF — 113ºF) Temperature Storage -10ºC — 60ºC (-14ºF — 140ºF) Temperature Maximum <95% (non-condensing) Humidity RS-232 RxD, TxD according to TIA/EIA-232-F 1-D barcodes: Codabar, Code 39, Code 128, and Code 93, Interleaved 2 of 5, MSI, Pharma, Codes Postal, UPC/EAN/JAN 2-D barcodes: Data Matrix... -
Page 12: Dataman 503 Imager Specifications
DataMan 503 Imager Specifications Specification DataMan 503 Imager Image Sensor 2/3 inch CMOS Image Sensor Properties 5.5μm square pixels Image Resolution (Pixels) 2048 x 1088 Image Acquisition Maximum 150 fps Lens Type C-mount lens... -
Page 13: Compliance Statements
2014/30/EU Electromagnetic Compatibility Directive. For further information please contact: Cognex Corporation, One Vision Drive Natick, MA 01760 USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE. -
Page 14: For European Community Users
UL and cUL listed: UL60950-1 2nd ed. and CSA C22.2 No.60950-1 2nd ed. Statement For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). -
Page 15: China Rohs
(PBDE) 六 价 铬 多 溴 二 苯 醚 DM503 This table is prepared in accordance with the provisions of SJ/T 11364. 这 个 标 签 是 根 据 SJ / T 11364 的 规 定 准 备 的 。... - Page 16 Copyright © 2017 Cognex Corporation. All Rights Reserved.
