  • Page 1 ® DataMan Quick Reference Guide 2021 November 25 Revision: 6.1.11.1...
  • Page 2 Precautions To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: Route cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply.
  • Page 3 Symbols The following symbols indicate safety precautions and supplemental information: WARNING: This symbol indicates a hazard that could cause death, serious personal injury or electrical shock. CAUTION: This symbol indicates a hazard that could result in property damage. Note: This symbol indicates additional information about a subject. Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.

  • Page 4: Product Overview

    Product Overview Status LEDs: - YELLOW - GREEN - RED Cable Internal illumination 3-position M12 lens LED aimer Mounting holes (M3 x 3.5 mm) Remove side cover to access square nut (M3)
  • Page 5 Yellow arrow indicates selected focus position Hidden square nut as an alternative mounting option...

  • Page 6: Dataman 50 Accessories

    DataMan 50 Accessories CABLES USB Cable, 1.5 m (DM100-USB-000), USB Cable, 3 m (DM100-USB-030) USB and Flying Leads I/O Cable, 2.0 m (DM-USBIO-00) RS-232 and Flying Leads I/O Cable, 2.5 m (DM-RS232IO-00) RS-232 Cable, 1.5 m (DM100-RS232-000), Extension Cable, 5 m (DM100-EXTCBL-000)
  • Page 7 Dimensions...

  • Page 8: Field Of View And Reading Distances

    Field of View and Reading Distances Focus position Distances in mm/2D min. code Distances in mm/1D min. code 6 MIL 45 mm 33-51 34-51 4 MIL 31-57 8 MIL 30-56 6 MIL 27-60 10 MIL 37-66 10 MIL 25-61 12 MIL...
  • Page 9 70 mm 44-74 6 MIL 52-73 4 MIL 42-78 8 MIL 45-83 6 MIL 39-80 10 MIL 33-89 10 MIL 34-89 12 MIL 110 mm 58-121 10 MIL 66-122 6 MIL 54-133 12 MIL 50-141 10 MIL 58-168 15 MIL...

  • Page 10: Connecting The Reader

    Connecting the Reader Perform the following steps: 1. Connect the breakout cable. 2. Connect the reader to the PC. For information on the pinout and the wire colors, see section Connections, Optics and Lighting in the DataMan 50 Reference Manual.

  • Page 11: Installation

    1. After installing the software, connect the DataMan 50 to your PC. 2. Launch the DataMan Setup Tool and click Refresh. 3. Select your DataMan 50 Series reader from the list and click Connect. Mounting Mounting the DataMan reader at a slight angle (15°) can reduce reflections and improve performance.

  • Page 12: Connect The Breakout Cable

    Connect the Breakout Cable Note: You can clip unused wires short or use a tie made of non-conductive material to tie them back. For RS-232, use the Power Supply return path for ground. 1. Verify that the power supply being used is unplugged and not receiving power.

  • Page 13: Dataman 50 Specifications

    DataMan 50 Specifications Weight 76 g (including cable) Operating 0 ºC — 40 ºC (32 ºF — 104 ºF) Temperature Storage Temperature -10 ºC — 60 ºC (-14 ºF — 140 ºF) Maximum Humidity 95% (non-condensing) Environmental IP65 if sealing is installed properly Vibration EN61373 including IEC 60068-2-6,60068-2-64 6.4, and 60068-2-27...
  • Page 14 Discrete I/O Output 0,1 @ 24 VDC 25 mA Operating Limits 26 V Output 2 Source V Sink V 4 V - V 0 — 2 V Input 0 (Trigger) V IH 4 — 26 V Input 1 V IL 0 —...

  • Page 15: Dataman 50 Imager Specifications

    DataMan 50 Imager Specifications Specification DataMan 50 Series Imager Image Sensor 1/3 inch CMOS Image Sensor Properties 4.51 mm x 2.88 mm (H x V), 6.0 µm square pixels Image Resolution (pixels) 752 x 480 Electronic Shutter Speed 18 µs to 25 ms exposure...

  • Page 16: Compliance Statements

    2014/30/EU Electromagnetic Compatibility. For further information please contact: Cognex Corporation, One Vision Drive Natick, MA 01760 USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked.

  • Page 17: Led Safety Statement

    Safety and Regulatory FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital Compliance Statement device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.

  • Page 18: For European Community Users

    For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). This product has required the extraction and use of natural resources for its production.

  • Page 19: China Rohs

    China RoHS Hazardous Substances 有 害 物 质 Part Name Lead (Pb) Mercury Cadmium Hexavalent Polybrominated Polybrominated 部 件 名 称 铅 (Hg) (Cd) Chromium biphenyls (PBB) diphenyl ethers 汞 镉 多 溴 联 苯 (Cr (VI)) (PBDE) 六 价 铬 多...
  • Page 20 Copyright © 2021 Cognex Corporation. All Rights Reserved.
