- Page 1 HO862300TX Hendrik Apothecary Desk For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Hendrik Apothecary Desk Parts List Please check packaging for all parts and hardware before discarding. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage. Quantity Quantity Quantity...
- Page 3 Quantity Quantity Quantity of 1 of 1 of 1 Left Drawer Side Panel Right Drawer Side Panel Drawer Back Panel Quantity Quantity Quantity of 1 of 1 of 1 Drawer Bottom Panel Big Drawer Left Side Panel Big Drawer Right Side Panel Quantity Quantity Quantity...
- Page 4 Quantity Quantity Quantity of 16 of 2 of 15 Screws Hinges Screws Dia. 1/8”x1/2”L Dia. 1/8”x1/2”L Quantity Quantity Quantity of 1 of 4 of 1 Magnet Plate Shelf Pins Magnet Quantity Quantity Quantity of 4 of 4 of 12 Bolts Metal Nuts Screws Dia.
- Page 5 Hendrik Apothecary Desk Assembly Instructions Start with fingers to help align cam bolts before using screwdriver. Insert Cam Locks (B) into holes on Upper Back Panel (6). Screw Cam Bolts (A) into threaded holes on Left Side Panel (2) and Middle Panel (4). Attach Left Side Panel (2) to Upper Back Panel (6) using Cam Bolts (A).
- Page 6 Insert Cam Locks (B) and Wood Dowels (C) into holes on assembled unit. Screw Cam Bolts (A) into threaded holes on Top Panel (1). Attach Top Panel (1) to assembled unit by inserting Cam Bolts (A) and Wood Dowels (C) into holes until all components meet.
- Page 7 Start with fingers to help align screws. Attach Hinges (H) to Side Panel (3) and Right Door (10) with Screws (I). Attach Magnet Plate (J) to door with Screws (I). Attach Knobs (P) to door with Bolts (Q). Attach Magnet (L) to unit using Screws (G). Insert Shelf Pins (K) into holes.
- Page 8 Connect Big Drawer Back Panel (19) to Big Drawer Bottom (20) using Wood Dowels (C). Attach using Screws (O). Connect Big Drawer Side Panels (17/18) to drawer using Wood Dowels (C). Use Bolts (M), Metal Nuts (N) and Screws (O) to attach Big Drawer Side Panels (17/18).
- Page 9 Now your Hendrik Apothecary Desk is ready to Figure 9 Page | 9...
-
Page 10: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
