After the selection of the WAN interface associated to the service to create, Figure 5-21 and Figure 5-22, use the Next button at Figure 5-22, to
progress to the next WAN Service setup window- Wan service Configuration, Figure 5-54.
At this window execute the following steps:
STEP 1.
Select the IP over Ethernet (GRE) WAN service type, Figure 5-54.
STEP 2.
It the Field Service Description enter a string for the service description; the default service description is a string automatically filled
in when the type o device is selected (Step1) and composed by the type of Service followed by underscore and the WAN interface
name , e.g. gre_veip0.
STEP 3. Use the Next button, Figure 5-54, to progress to the WAN Service setup window- GRE Tunneling Settings, Figure 5-55.
In this window two GRE configuration modes are available from a configuration mode combo box selection, ; The detail of the re-
quired information for setting the GRE will vary according to the configuration mode selected:
Basic
Advanced
Figure 5-54: WAN service setup – type of service selection and service configuration – GRE service
Figure 5-55: WAN Service setup window- GRE Tunneling Settings
