2.14.3 Dynamic Bandwidth Allocation (DBA)

The DBA (Dynamic Bandwidth Allocation) is available in order to optimize the upstream bandwidth. This mechanism consists in defining an ad-
equate T-CONT to the service traffic in question. There are five types of T-CONT, defined by the Fixed, Assured and Maximum Parameters:
Type 1: Only fixed Bandwidth;
Type 2: Only Assured Bandwidth;
Type 3: Assured+Maximum Bandwidth;
Type 4: Only Maximum Bandwidth (Best Effort);
T-CONT
Fixed BW- R
F
Assured BW- RA
Max Bw - RM
Bandwidth Eligi-
bility
In each GPON interface there are 1024 Alloc-ID (T-CONT identifiers) available, provided to manage ONT services. They are distributed in the fol-
lowing way:
Figure 2-11: Upstream QoS Diagram
Type 5: Fixed+Assured+Maximum Band
Type 1 Type 2
R 0
F1
R
0
A2
R = R R = R
M1 F1 M2 A2
0 0
Table 2-1: T-CONT types definition
Alloc-ID Allocation Type
0-127 Default Alloc-ID (Dynamic or Static)
128-255 Reserved
256-639 Dynamic or Static
640-1023 Static
Table 2-2: Alloc-ID's distribution by T-CONT type
Type 3 Type 4
0 0
R
0
A3
R > R R
M3 A3 M4
Non-Assured Best-Effort
BW - R - R
NA BE
Type 5 Units
R [b/s]
F5
R
[b/s]
A5
R
> [b/s]
M5
R + R
F5 A5
R / R
NA BE
