GPON ONT

7.CLI

7.1 Overview

The aim of this chapter is to describe the commands available from the ONT Gateway CLI.
The CLI has a "/cli>" prompt character, and it is available from the serial console, telnet login, and ssh logins.
CLI has a "directory-like" structure and the command "cd" should be used to navigate through the various nodes.
In order to see a list of available CLI commands, the user can type "tree" (to see all nodes within the current node and respective commands) or "dir"
(to see the available commands of the given node).
The command that the user wants to type may need arguments; in order to check the arguments of one command, the user can type "?" after it
(ex: /cli/wan/gre> create ?).
The same logic can be used with some arguments, for instance, the command "/cli/wan/ipoe> create --interface=?" will return the list of the avail-
able interfaces that can be used. (Note that when there is more than one mandatory argument, all of those arguments must be fulfilled, even if
the user wants to type '?' in one of them).
The "show" command has a screen output depending on the usage context: node or sub-node current configuration or information is displayed
on the screen.
To see the CLI basic usage, type "help".
To logout/quit CLI, type "quit".
Some command have restricted availability depending on the user profile permissions.

7.2 Nodes and Commands

7.2.1 "wan" node

This node allows a user to see, to add and/or to delete wan services. The available wan services are: IPoE, PPPoE, Bridging and GRE.
In order to configure one service, the user should enter the respective node (ex: /cli> cd ipoe) and then type the desired command.
The user can see the configured wan interfaces by typing "show" on the interfaces node.
+ wan[@show]
+ bridge[@create, @remove, @show]
+ gre[@create, @remove, @show]
+ interfaces[@show]
+ ipoe[@create, @remove, @show]
+ pppoe[@create, @remove, @show]
Figure 7-1: wan node tree
