Televes 769501 User Manual page 168

GPON ONT
7.2.3.3 "nat1:1" sub-node
1:1 NAT is a mode of NAT that maps one internal address to one external address
7.2.3.3.1 "create" command
Name
Description
Full path
Arguments
<MANDATORY>
7.2.3.3.2 "remove" command
Name
Description
Full path
Arguments
<MANDATORY>
7.2.3.4 "port-triggering" sub-node
Some applications require that specific ports in the Router's firewall be opened for access by the remote parties. Port Trigger dynamically opens up
the 'Open Ports' in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the 'Triggering Ports' . The
Router allows the remote party from the WAN side to establish new connections back to the application on the LAN side using the 'Open Ports' .
7.2.3.4.1 "create" command
Name
Description
Full path
Arguments
<MANDATORY>
create
Creates a new entry on the NAT 1:1 list
/nat/nat1:1/create
--lan-ip LAN IP
--name Name
--public-ip Public IP
--wan-interface WAN interface
Table 7-19: "create" command information
remove
Removes an existing entry on the NAT 1:1 list
/nat/nat1:1/remove
--name Name
Table 7-20: "remove" command information
create
Creates a new entry on the Port-triggering list
/nat/port-triggering/create
--name Application Name
--open-port-end Open port end
--open-port-start Open port start
--open-proto Open Protocol <TCP/UDP|TCP|UDP>
--trigger-port-end Trigger port end
--trigger-port-start Trigger port start
--trigger-proto Trigger Protocol <TCP/UDP|TCP|UDP>
--wan-intf Interface
Table 7-21: "create" command information
