Specifications; Heating Specifications; Dimensions; Electrical Specifications - Avalon Arbor PS Owner's Manual

6

Heating Specifications

Approximate Maximum Heating Capacity (in square feet)* ........................................800 to 2,250 Sq. Feet
Burn Rate (Pounds per Hour)**............................................................................1.7 to 5.5
Maximum Burn Time on Low Burn** ......................................................................29 Hours
Hopper Capacity ..............................................................................................50 Pounds
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature. It is also affected
by the fuel size, quality, and moisture level.
** Small pellets will increase or decrease the stated burn rates and burn times. Differences of plus or minus 20% depending on fuel
quality may occur.

Dimensions

25"
Weight: 390 Lbs.

Electrical Specifications

Electrical Rating.........................................................................................115 Volts, 3.6 Amps, 60 Hz
Watts During Start-Up Sequence ...................................................................400 (approximately)
Watts During Operation ...............................................................................180 (approximately)

Fuel

• This heater is designed and approved for pelletized wood fuel or a mixture up to 50% corn, 50% pellets.
See page 26 for details on using a corn pellet mix.

EPA Compliance

This heater has been tested exempt from EPA Phase II Requirements by OMNI-Test Laboratories, Inc.
© Travis Industries

Specifications

27-3/4"
4070806
27-1/4"
NOTE:
Measure front and side clearances from the
stove top. Rear and corner clearances are
measured from the stove body.
7-3/4"
17-1/4"
4" Diameter
Exhaust
27"
1 0 0 - 0 1 1 9 1 _ 0 0 0
