Loading Pellets

Lift the hopper lid to its vertical position. Pour pellets into the hopper until full. NOTE: The hopper
holds approximately 50 pounds of pellets.
To Open the Hopper Lid:
Lift the hopper lid from this handle.
Warning:
The front edge of the
stove top becomes very
hot, do not touch this
area below the handle.
HINT : To prevent the pellet stove from inadvertently shutting down due to the auger disabling switch, we
recommend pressing the "START" button after reloading the stove.

The Two Modes of Operation

Manual
Manual mode requires the user to turn
the heater on and off manually.
Auto (requires a thermostat)
Auto mode allows you to use a
thermostat to control room
temperature. The stove automatically
turns on when the temperature drops
below the thermostat setting. Once the
stove reaches operating temperature,
the stove then runs at the heat output
setting selected.
Switching Modes While in
Operation
Whenever the stove is switched from
one mode to another while in
operation, the stove will enter the "start-
up" sequence for a minimum of 20
minutes.
© Travis Industries
Operation
NOTE:
The auger automatically shuts off when the hopper
lid is open. If loading pellets while the heater is on,
make sure to close the lid as soon as possible.
This prevents the heater from shutting off due to
lack of pellets in the firepot.
DISCONNECT POWER BEFORE SERVICE
H
E
A
T
O
U
T
P
U
T
H
E
A
T
F
A
N
4070806
REMOTE
HIGH
AUTO
MANUAL
MED
AUGER
LOW
FAULT
AUTO
UP OFF
MANUAL
MANUAL
DOWN
START
UP
MANUAL
DOWN
AUGER
TM

TRAVIS INDUSTRIES

HOUSE OF FIRE
NOTE: if using a
modulating remote, this
light will come on to
indicate the remote is
controlling the heater.
These indicator lights
are used to determine
which mode you are in.
Use the mode
switch to
determine the
mode.
1 0 0 - 0 1 1 9 1 _ 0 0 0
2 1
