Bi-Weekly Maintenance (or every 10 bags of pellets) - continued
Clean the Baffles
WARNING : Make sure the heater has fully cooled (approximately 25 minutes) before conducting service.
HINT :
The more often you clean out flyash, the more efficient your heater will burn.
The baffles are found along the top of the firebox. The front edge has a slot that slides into a hook on
the top of the firebox. The back rests on the back refractory. To remove, slide them inwards, pull
them forward, and tilt them back to allow the accumulated flyash fall off into the firebox. Replace after
cleaning.
© Travis Industries
Maintenance
4070806
1 0 0 - 0 1 1 9 1 _ 0 0 0
3 1
