replacing the cable

To replace the cable, proceed as follows:
- remove the back panel of the weight stack (following the instructions found in the
section Removing the weight stack panel);
- loosen the screws (A) on the tie rod (B);
- back off the lock nut (C) and unscrew the adjuster (D);
- extract the cable from the adjuster side;
Low Row
A
B
D
C
cont. 16
