Page 1: User Manual
E L E M E N T E S S E N T I A L S T R E N G T H Low Row User manual All equipment... -
Page 2: Table Of Contents
Contents Identification of the manufacturer and the equipment ....3 Description of the equipment ............ 4 Technical data ................5 Safety labels and warnings ............6 Place of installation ..............7 Unpacking ................. 8 Lifting and handling the equipment ......... 10 Adjusting the equipment ............ -
Page 3: Identification Of The Manufacturer And The Equipment
Identification of the manufacturer and the equipment The identification plate of the equipment and manufacturer, affixed on the frame, gives the following details: A Name and address of the manufacturer B CE Mark C Serial number D Cautions and maximum user weight E Equipment classification ELEMENT+ SILVER-BLU AVI CB350C0 - ALK0GGGK... -
Page 4: Description Of The Equipment
Description of the equipment Seat (A): where the user sits to perform the exercise. Its position can be adjusted using the seat lever (B). Exercise levers (C): operated by the user by means of the handgrips (D). Chest pad (E): the user’s chest rests against it during the exercise. Fixed handgrip (F): can be grasped with the resting arm when training one arm at a time. -
Page 5: Technical Data
Technical data 970 mm 1190 mm (38") (47") 1421 mm (56") 08093016 170 kg (375 lb) 80 kg (160 lb) Low Row... -
Page 6: Safety Labels And Warnings
Safety labels and warnings The equipment does not have any sharp corners. All the parts which come into contact with the body are adequately protected with rubber coverings or padding. The weight stack is enclosed in protective panels. WArnInG It is important to pay attention to the labels affixed to the equipment, as they provide information about possible risks and hazards. -
Page 7: Place Of Installation
Place of installation To guarantee safe, comfortable and effective use of the equipment, the place of installation must comply with certain specific requirements; in particular, before choosing where to install the equipment it is recommended to check the following: temperature between +10°C and +25°C; sufficient ventilation to maintain a humidity level between 20% and 90%, when the equipment is in use;... -
Page 8: Unpacking
Unpacking The equipment is supplied fully assembled in a carton and protected by cellophane wrapping, and secured to a pallet. The equipment can be lifted and handled using normal lifting machine. In order to ensure the safety of persons and property, carefully determine the lifting and handling machine used as a function of the place of installation. - Page 9 Unpacking remove the spacer from between the two panels of the weight stack. WArnInG Given the weight of the equipment, we recommend that more than one person be involved in lifting it. The packing materials (boxes, bags, etc.) must not be left within the reach of children, as they constitute a possible hazard;...
-
Page 10: Lifting And Handling The Equipment
Lifting and handling the equipment To move the equipment, use normal lifting and handling machine. It is recommended to place some padded material between the frame and the lifting machine. DAnGEr The equipment must be moved with great care, due to the risk of it tipping over. Before lifting the equipment, insert between the two panels of the weight stack the spacer provided at the time of delivery. - Page 11 Lifting and handling the equipment WArnInG When lifting the equipment, do not exert pressure against the weight stack guards. 04251021 Low Row...
-
Page 12: Adjusting The Equipment
Adjusting the equipment After the equipment has been positioned on the floor, check that it is level. The foot (A) is adjustable for this purpose: loosen the lock nut (B) and tighten or loosen the foot until the equipment is stable. When this is done, close the lock nut (B). -
Page 13: Routine Maintenance
routine maintenance WArnInG The safety of the equipment is assured only on condition that it is carefully inspected for signs of damage and/or wear every two weeks. replace defective and worn components immediately, or alternatively remove the equipment from service. The equipment should always be kept clean and free of dust, in compliance with good hygiene practice, especially if it is used in a gym or by more than one person. - Page 14 (following the instructions found in the section Removing the weight stack panel in reverse order). For maintenance actions not described in this manual, call in the Technogym Technical Service. Low Row...
-
Page 15: Replacing The Padded Components
replacing the padded components If any of the padded components show signs of wear, it is advisable, especially in the interests of hygiene, to replace them completely. In order to replace the seat loosen the screws on the opposite side to the padding. Handgrips are removed after unscrewing the screws (A). -
Page 16: Replacing The Cable
replacing the cable To replace the cable, proceed as follows: remove the back panel of the weight stack (following the instructions found in the section Removing the weight stack panel); loosen the screws (A) on the tie rod (B); back off the lock nut (C) and unscrew the adjuster (D); extract the cable from the adjuster side;... - Page 17 replacing the cable insert the new cable beginning on the adjuster side (follow the original path of the cable as shown in the figure); WArnInG Pay close attention when passing the cable through the hole in the front panel of the weight stack. Low Row cont.
- Page 18 (following the instructions found in the section Removing the weight stack panel in reverse order). DAnGEr ALWAYS use cables supplied directly by Technogym. The cables must always be replaced at the first sign of wear, even if it only affects the outer rubber protection.
-
Page 19: Adjusting Cable Tension
Adjusting cable tension It is possible to take up some of the slack in the weight stack cable using the adjuster (D), after loosening the lock nut (C). For this purpose, you will need to remove the back panel of the weight stack (following the instructions found in the section Removing the weight stack panel). -
Page 20: Removing The Weight Stack Panel
removing the weight stack panel The weight stack panel is attached to the frame with 6 screws. To disassemble the panel (A): unscrew the 6 screws (B) while holding the panel with one hand; remove the panel. To reassemble the panel, carry out the above steps in reverse order. Low Row... -
Page 21: Technical Service
When contacting the Technogym Technical Support Service, please specify the following details: equipment model, date of purchase, serial number, precise description of the problem. WArnInG Any operations on the equipment carried out by persons not authorized by Technogym will invalidate the warranty. Low Row... -
Page 22: Storage
Storage If the equipment will not be used for a prolonged period, it is recommended to store it: in a clean and dry place, covered with a cloth to protect it from dust; in an environment with a temperature between +10°C and +25°C and a humidity between 20% and 90%. For correct storage, use the original packing materials. -
Page 23: Using The Equipment
Using the equipment Sit facing the handgrips (A). Pull up the lever (B) under the back of the seat to set the height so that the chest pad (C) is halfway up your breastbone. To lower the seat you can remain seated; un-weight the seat to raise it. Select the workload with the pin (D). - Page 24 Using the equipment 04251029 Pull with both arms simultaneously until they are fully bent, then extend your arms. Maintain a smooth controlled speed through the movement while staying in control of the weight. In the return movement of the last repetition, stand up and let go of the handgrips, lowering the load down slowly.
