Packing List
•
Glass Frame
•
(4) Mounting Brackets (2 left, 2 right)
Installation
1
Remove and discard the four side glass brackets on the glass frame (see Figure 1, item "a"). Attach the
mounting brackets included with this kit to the back of the glass frame, using the nuts removed earlier - make
sure the brackets are installed with the notch on the lower side of the bracket (see Figure 1, item "b").
2
Attach the glass frame to the fireplace by inserting the tabs on the mounting brackets into the slots on the
fireplace (see Figure 2). Magnets hold the mounting brackets in place.
Page 1 of 1
Illuminations 4915 Electric Fireplace
Glass Frame Installation Instructions
17601562 - 12/16/08
Figure 1
Figure 2
(sku 95000964)
© Travis Industries, Inc.
