- Page 2 Trademarks Copyright © PLANET Technology Corp. 2003. Contents subject to revise without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
-
Page 3: Table Of Contents
PERATION TEPS 3.3 Q ............. 25 UICK IAL EXAMPLE 3.3.1 Dial to local in peer to peer (P2P) mode ....25 3.3.2 Phone Book web configuration sample....26 4. QUICK REFERENCE IN CD-ROM GUIDE ..... 27 VIP-100T Quick Installation Guide... -
Page 4: Overview
1. OVERVIEW Thank you for purchasing PLANET IP Phone VIP-100T (VIP-100T, in the following terms). You can now ease the cost of long distance call yet still enjoy the toll voice quality via Internet. This Guide contains the following information:... -
Page 5: Before Startup
1.1 Before Startup Before your first time start up, please check if the package comes with following items: VIP-100T Your manual CD Quick Installation Guide RJ-45 cable And later, you are required to familiar your environment, your TCP/IP network and your phone systems. -
Page 6: Front View And Keypad Function
[Indicate Forward Type]) ♦ MESSAGE and its indicated LED light: When missing the incoming calls, the message LED will be flashing. You can know the information of miss call by pressing the message button. VIP-100T Quick Installation Guide... - Page 7 7 “P” ; “Q” ; “R” ; “S” ; “7” 8 “T” ; “U” ; “V” ; “8” 9 “W” ; “X” ; “Y” ; “Z” ; “9” “-“ ; “?” ; “*” 0 “0” # “_” ; “@” ; “#” PLANET VoIP...
-
Page 8: Rear View
Two LED indicated lights; LNK/ACT and 10/100 for LAN port and PC port. When network status is in Display normal, LED of LINK/ACT will be flashing; when transmit rate is in 10 Mbps/100Mbps, LED of 100 will light off/on. VIP-100T Quick Installation Guide... -
Page 9: Basic Configuration
2. BASIC CONFIGURATION This chapter shows you the starting point of VIP-100T to be integrated into your network and/or Internet. Configuration steps in this quick guide will be focused on keypad configuration. More detail configuration, including keypad, web, and telnet instructions will be illustrated in respective chapters in user’s... -
Page 10: Lcd Configuration
12. Management Center 13. GRQ Option Gatekeeper ID In this session, we will introduce the main configuration of VIP-100T for you to quickly and easily to establish voice communication. 2.1.2.1 System Configuration Please Enter Password: You’ll see this prompt each time when you try to configure or modify parameters in VIP-100T. -
Page 11: (I) Connect Configuration
ITSP, please insert the parameter in order to complete configuration. (1) IP address In this configuration mode, please press the prepared IP Address on the VIP-100T keypad, the IP address format should be: xxx.xxx.xxx.xxx. (2) Subnet Mask: Please insert proper subnet mask parameter via keypad. - Page 12 IP address) (7) Second GateKeeper VIP-100T provides alternative GateKeeper feature, if VIP-100T can’t register to Main GateKeeper for 10 times, it will try to register to the Second GateKeeper. When main GateKeeper can’t work normally, VIP-100T can still keep working with Second GateKeeper If you cannot ensure the GK related parameters, please consult your ITSP for proper GK information.
- Page 13 Please specify a SNTP server for VIP-100T to obtain current time information. (b) Time Zone: You can set time zone according to the location VIP-100T is. For example, in Taiwan the time zone should be set as 8,which means GMT+8, in the meantime, you may press “*”...
- Page 14 This option is reserved for support service, please leave this in default configuration (255.255.255.255).. (13) GRQ Option In GK operation environment, VIP-100T can find the GK via auto discovery function. If this function is enabled and IP address of GateKeeper is set as 255.255.255.255,...
-
Page 15: (Ii) User Line Number
(ii) User Line Number While machine is operating in GK mode, you’ll need to configure at least one number for the VIP-100T to register to the GateKeeper. Up to 10 different numbers can be setup in VIP-100T. (1) Line Number 1... -
Page 16: (Iv) Hardware Test
Please follow the messages on LCD panel to complete the self-diagnostics. (v) Reboot If modification is made to VIP-100T, please confirm all the parameters are properly configured, and use this Reboot option to make the changes effective. -
Page 17: Making Calls
3.MAKING CALLS There are several ways to make calls to desired destination in VIP-100T. In this chapter, we’ll lead you step by step to establish your first voice communication via keypad operations.. 3.1 IP address call (P2P mode): Please go to third level of configuration menu, and press ç or è... -
Page 18: P2P Mode Operation Steps
Configuration Configuration 3. Gateway (a) Go to third level of VIP-100T’s configuration menu, and press ç or è and OK button to select IP address, and insert value via keypad. (b) Go up one level, and press ç or è and OK button to select Subnet Mask, and insert value via keypad. - Page 19 VIP-100T default running mode is P2P mode. If you’d like to connect others via GK mode, the setup procedure of VIP-100T can be referred in the next Note section. After setting up networking parameters, you may directly dial the destination IP address to establish the voice communication toward desired personnel.
- Page 20 If the call cannot be made, please check if all the TCP/IP parameters are correctly configured, and matched with network environment Hint parameters assigned by your ISP. VIP-100T Quick Installation Guide...
-
Page 21: Gk Mode Operation Steps
Level Level Machine default running mode is P2P mode. If you’d like to connect others via GK mode, the setup procedure of VIP-100T can be referred below: (a) Go to third level of the LCD display configuration menu, and press ç or è and OK button to select Gatekeeper. Insert Gatekeeper server IP Address via VIP-100T’s keypad. - Page 22 (b) Press C twice to go back to LCD menu first level, and press ç or è and OK button to select User Line Number. (c) You’ll need to insert at least one number for VIP-100T to register with Gatekeeper for voice communication. Up to 10 different direct line numbers can be configured in VIP-100T.
- Page 23 (e) Go to second level of the LCD display configuration menu, and press ç or è and OK button to select Reboot It is required and important for you to reboot VIP-100T to make the changed parameters Caution effective. After rebooting, you may now place calls toward other H.323 gateway/terminal via the GK.
-
Page 24: Quick Dial Example
Then the phone in 192.168.0.2 should rings. You can do the same thing from the second VIP-100T. If you already know the IP address of the remote side as well as you can reach it by ping, you can direct make dial via its IP address and end with an “#”. -
Page 25: Phone Book Web Configuration Sample
3.3.2 Phone Book web configuration sample Assuming you’d like to place a call toward PLANET Office, the call setup example could be as like following: Please logon VIP-100T web configuration, and choose “Phone Book” configuration. Insert following parameters Index number: 7 Destination Name: PLANET Office, Domain name: vip.planet.com.tw... -
Page 26: Quick Reference In Cd-Rom Guide
4.QUICK REFERENCE IN CD-ROM GUIDE This guide is used to help you startup your VIP-100T settings. It is also recommended to check the CD-ROM manual for more details like the chapter “Web Setup” and “Telnet Configuration”, and how to set the device back to factory default value.
