3. Display

3.1 Display Screen

Short press on
Danfoss Eco™ is displaying the set temperature, not the measured room temperature.
Display symbols:
Installation Mode must always be activated when installing or removing Danfoss
Eco™. The thermostat may be irreparably damaged if not in the correct position during
installation.
Temperature is shown in degrees celcius. Danfoss Eco™ is displaying the set temperature,
not the measured room temperature.
Scheduled Mode
The antenna symbol flashes when you need to connect the App to the thermostat.
If you are connected, the red ring will illuminate (the display will be blank).
low battery. Battery icon will flash in display.
If battery level is critical the red ring will flash.

3.2 Red illuminating ring

The red ring will be constantly on when you are connected to the Danfoss Eco™ App. It also
flashes to indicate when the batteries are critically low on power.
VILTH102
Danfoss Eco™ Electronic radiator thermostat
and the Display Screen appears.
