connection is closed, or the link is interrupted. In this mode, the trans-
ceiver behaves the same, whether it is an Access Point or a Remote.
(See Figure 3-31 and
NOTE: The TCP session has a timeout of 10 minutes (600 seconds). If
inactive for that time, it will be closed. The transceiver will
offer the port again for connection after this time expires.
From the PC, establish a TCP connection to the IP address of the
Remote transceiver and to the IP port as configured above (30010—
COM1, 30011—COM2). A Telnet client application can be used to
establish this connection. Data can now be sent between the PC and the
RTU or other connected device.
192.168.0.10
Ethernet
Crosssover
Computer
or Network
Figure 3-31. IP-to-Serial Application Diagram
Table 3-1. Serial Port Application Configuration
Transceiver
Location
Access Point
Remote Unit
3.6.7 Point-to-Point Serial-to-Serial Application
Example
Once the transceivers are configured and the changes have been exe-
cuted, they begin processing any data presented at the
presented at the Access Point's
UDP to the Remote. Upon receiving the packet, the Remote strips the
data out of the UDP packet and sends it out its
presented at the Remote's
Point, stripped, and sent out the Access Point's
configuration does not use multicast addressing.
