Packet Redundancy Mode
Serial Packet Redundancy mode must match (Single Packet
mode vs. Packet Repeat mode). This is because a transceiver,
when in Packet Repeat mode, sends 12 extra characters
(sequence numbers, etc.) to control the delivery of the
repeated data. Misconfigurations can result in undesired
operation.
• —Data rate (payload) for the
Data Baud Rate
bits-per-second. [
1,200–115,200; 19200
• —Formatting of data bytes. Data bits, parity and
Configuration
stop bits [
7N1, 7E1, 7O1, 8N1, 8E1, 8O1, 8N1, 7N2, 7E2, 7O2, 8N2,
].
8E2, 8O2; 8N1
• (COM2 only)—RTS/CTS handshaking between
Flow Control
the transceiver and the connected device.
[
Enable, Disable; Disabled
• — When seamless mode is selected, data bytes
Serial Mode
will be sent over the air as quickly as possible, but the
receiver will buffer the data until enough bytes have arrived
to cover worst case gaps in transmission. The delay intro-
duced by data buffering may range from 22 to 44 ms, but the
radio will not create any gaps in the output data stream. This
mode of operation is required for protocols such as MOD-
BUS™ that do not allow gaps in their data transmission.
[
Seamless, Custom; Seamless
•
Seamless Inter-Frame Delay
sent the end of a message (inter-character time-out). MOD-
BUS defines a "3.5-character" parameter. [
•
Custom Data Buffer Size
mum amount of characters, that the Remote end will buffer
locally before starting to transmit data through the serial port.
[
16, 32, 64, 128, 256; 32
•
Commit Changes and Exit Wizard
made on this screen (Shown only after changes have been
entered.)
MDS iNET 900 Series User's Guide
— For proper operation, all radios'
]
]
]
— Number of characters that repre-
(Custom Packet Mode only)—Maxi-
]
—Save and execute changes
port in
COM
]
1–65,535; 4
