A-12
The following tables specify the ratings for the drive sections.
The notes concerning the following drive section tables are listed
below.
P P is the heat loss of a unit with basic options.
loss loss
Noise level applies to echoless room.
The height of the cabinet for IP 21/22/42 classification is 2065 mm up
to frame type R7i. The height of frame type R8i and above is 2130 mm.
Cabinet height is 2072 mm for IP 54R classification.
The depth of the cabinet is 600 mm.
Note Description
1 200 mm is added with the top exit
2 400 mm is added with the top exit
3 600 mm is added with the top exit
4 800 mm is added with the top exit and/or common motor
connection terminals
5 600 mm is added with the top exit and/or common motor
connection terminals
6 The width is 400 mm with no options and 600 mm when
optional devices are included. 600 mm is added when more
than one inverter unit is used in the drive section.
7 200 mm wide joining cabinet is added (max. transportation
length is 4000 mm)
Weight
kg
40
110
160
230
190
40
PDM code 00004863-D
ACS 600 MultiDrive
