4Y Series
UYA 4Y Ultra-microbalances
MYA 4Y Microbalances
MYB 4Y Microbalances
MYA 4Y.P Microbalances
MYA 4Y.F Microbalances
XA 4Y Analytical balances
XA 4Y.A Analytical balances
XA 4Y.F Analytical balances

USER MANUAL

IMMU-01-15-06-17-EN
www.radwag.com

Advertisement

Table of Contents
loading

Related Manuals for RADWAG UYA 4Y

Summary of Contents for RADWAG UYA 4Y

  • Page 1: User Manual

    4Y Series UYA 4Y Ultra-microbalances MYA 4Y Microbalances MYB 4Y Microbalances MYA 4Y.P Microbalances MYA 4Y.F Microbalances XA 4Y Analytical balances XA 4Y.A Analytical balances XA 4Y.F Analytical balances USER MANUAL IMMU-01-15-06-17-EN www.radwag.com...
  • Page 2 If you are reading this, it means that you are bound to achieve success. You have purchased a device that was designed and manufactured to give you years of service. Congratulations and thank you for selecting RADWAG product. JUNE 2017...

  • Page 3: Table Of Contents

    CONTENTS General Information ..................9 1.1. Dimensions ................... 9 1.2. Connectors ..................12 1.3. Intended Use ..................12 1.4. Precautions ..................12 1.5. Warranty Conditions ................13 1.6. Metrological Parameters Monitoring ............13 1.7. User Manual Significance ............... 13 1.8. Balance User Training ................13 Transport and Storage ................
  • Page 4 12. Permissions levels ..................32 13. Profiles ...................... 34 13.1. Creating a Profile ................. 34 13.2. Profile structure ................... 35 13.2.1. Settings ....................36 13.2.2. Working Modes ..................36 13.2.3. Readout ....................36 13.2.4. Measuring Units ................... 37 14. Working Modes ..................38 14.1.
  • Page 5 19.4. Supplementary Settings for Percent Weighing Mode ......... 66 20. Density ...................... 66 20.1. Density Determination Kit ..............67 20.2. Installation Procedure: ................67 20.3. Solids Density Determination ..............68 20.4. Determining Density of Liquids ............... 68 20.5. Air Density ..................69 20.6.
  • Page 6 27.2. Means of Operation ................104 28. Prepackaged Goods Controls ..............105 28.1. Prepacked Goods Control Mode Start-Up ..........105 28.2. Control Settings ..................106 28.3. PGC Mode Local Settings ..............106 28.4. Editing Product for Control ..............107 28.5. Control Start Procedure ................108 28.6. Abort Control Procedure ...............109 28.7.
  • Page 7 31.4. TCP Settings ..................144 32. Peripherals ....................144 32.1. Computer ...................144 32.2. Printer ....................145 32.3. Barcode Scanner .................146 32.3.1. Barcode Scanner’s Port ............... 147 32.3.2. Prefix/Suffix..................147 32.3.3. Field Selection ................... 147 32.3.4. Test ....................148 32.4. Transponder Card Scanner ..............149 32.5.
  • Page 8 - 8 -...
