  • Page 1 391695 391696 391715 391716/391717 Instructions manual...
  • Page 2 391695 / 391696 / 391715 / 391716 / 391717 IMPORTANT SAFETY GUIDE Read, heed and follow all the Instructions Read all the safety and operating instructions before using the product. Keep this manual Keep this manual for reference in future.
  • Page 3 CAUTION Operating Before using, make sure that the power supply and others are properly installed. While operating, if any abnormal condition or malfunction is observed, stop using the product immediately and then contact your local dealer. Handling Do not disassemble or tamper with the parts inside the product. Do not drop or subject the product to shock and vibration as this can damage the product.

  • Page 4: Table Of Contents

    391695 / 391696 / 391715 / 391716 / 391717 TABLE OF CONTENTS Introduction Model Code Features Package Components Main Part Description Installation DIP Switch Setup In-Ceiling Mount Installation (MPS) Installation with Surface Mount Bracket (MPS) Direct Installation on the Ceiling Mount Bracket(MPS)

  • Page 5: Introduction

    1. INTRODUCTION 1.1 MODEL CODE Ref. 391695 391696 391715 391716 391717 Mini plastic Mini Aluminium Mini Aluminium Aluminium with Aluminium Serie small with fan/heater with fan/heater fan/heater with fan/heater Outdoor serie Video signal Wall mount bracket Rated power : 12 VDC...

  • Page 6: Features

    391695 / 391696 / 391715 / 391716 / 391717 1.2. FEATURES Powerful Zoom Camera & Setup Options 391695 391696 391715 391716 391716 ×10 Optical Zoom ×10 Digital Zoom ×100 ×324 Max. zoom magnification x100 x324 x444 High light compensation Privacy Masks Day &...
  • Page 7 The information such as Camera ID, Pan/Tilt Angle, Direction, Alarm Input and Preset is displayed on screen. Alarm In/Out Function 391696 : 4 alarm sensor inputs and 2 alarm output relays 391695/391715/391716/391717 : 3 alarm sensor inputs and 1 alarm sensor outputs Alarm sensor input is decoupled with photo-couplers to avoid external electric noise and shock perfectly.

  • Page 8: Package Components

    391695 / 391696 / 391715 / 391716 / 391717 1.3. Package Component (391695 Model) Product & Accessories Main Body & Surface Mount Bracket Default Accessories [Main Cable, Calblock, Screws : Tapping M4×16, Tapping M4×25, Machine M3×6, Machine M3×8] I/O Cable...
  • Page 9 Package Component (391696 Model) Product & Accessories Main Body / Terminal Cover Dome Cover Screws Optional brackets In-Ceiling Mount Bracket Ceiling Mount Bracket Corner bracket Wall mount bracket 391885 391883 391849 391847...
  • Page 10 391695 / 391696 / 391715 / 391716 / 391717 Package Component (391715/391716/391717 Models) Product & Accessories Default Accessories Main Body & Surface Mount Bracket [Main Cable, Wrench] Accessories for The Models with Alarm In/Out Function Wall Mount Bracket [I/O Cable] [Screws : Machine M5×15, Hex Lag #14×50]...

  • Page 11: Main Part Description

    1.4. Main Part Description (391695 Model) Surface Mount Bracket Mounting Screw Hole Main Connector Sensor I/P Port Dome Cover Assembly Stud Dome Cover Lock-up Screw DIP Switch Dome Cover Dome Cover Do not detach the protection vinyl from the dome cover before finishing all the installation process to protect the dome cover from scratches or dust.
  • Page 12 391695 / 391696 / 391715 / 391716 / 391717 Main Part Description (391696 Model) Lockup Screw Terminal Cover Mounting Hole Drop Prevention Spring Fuse Cabling Drop Prevention Terminal Block Hook Main Body Connector Dome Cover Main Body / Terminal Cover...
  • Page 13 Main Part Description (391715 Model) Mo u n t in g Scr ew Ho le Mo u n t in g Ho o k DIP Swit ch Main Co n n ect o r Sen s o r I/ O Po r t Do m e Co ver Main Body / Terminal Cover Dome Cover...
  • Page 14 391695 / 391696 / 391715 / 391716 / 391717 Terminal Cover Disassembling ① Remove the Lockup Screw as shown bellow. ② Turn main body on its axis in CCW(Counter-clockwise) direction and separate it from Terminal Cover. Terminal Cover Assembling ① Check if the summit of the Plate Spring is located at the ②...

  • Page 15: Installation

    2. INSTALLATION 2.1 DIP Switch Setup (391695/391715/391716/391717 models) Before installing the camera, set up the DIP switch to configure the camera ID and the communication protocol. Camera ID Setup ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value Ex : ID=5 Ex : ID=10...
  • Page 16 391695 / 391696 / 391715 / 391716 / 391717 Communication Protocol Setup Select an appropriate Protocol with the DIP switch combination. Switch Mode Protocol (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps...
  • Page 17 Terminal Resistor Setup The terminal resistor is used for the following cases. Case 1 : In case that the control cable length between a camera and a controller is relatively very long (1:1 Connection) If the communication cable length is very long, the electrical signal will bound in the terminal point. This reflected signal causes distortion of original signal.

  • Page 18: Communication Protocol

    391695 / 391696 / 391715 / 391716 / 391717 DIP Switch Setup (391696 model) Before you install the camera, you should set the DIP switches to configure the camera ID, communication protocol. Do not use the ISP connector. (Authorized person only !)
  • Page 19 Communication Protocol Setup Select the appropriate Protocol with DIP switch combination. Switch State Protocol/Baud rate (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Otherwise Reserved If you want to control using DVR or P/T controller, their protocol must be identical to camera. Otherwise, you can not control the camera.
  • Page 20 391695 / 391696 / 391715 / 391716 / 391717 Terminal resistor Setup Terminal resistor is used if your system is one of following two cases. Case1: Control cable between camera and controller is relatively very long (1:1 connection) If communication cable is very long, the electrical signal will bound in the terminal point. This reflected signal cause distortion of original signal.

  • Page 21: In-Ceiling Mount Installation (Mps)

    2.2 In-Ceiling Mount Installation (391695 Model) ① ② Connect the wiring and cabling and attach the camera Remove the ceiling tile from the ceiling and cut a to the ceiling tile. (Tapping M4 × 16). hole whose diameter is 110mm on the ceiling tile to pass the wires and cables through to the upside of ceiling.

  • Page 22: Installation With Surface Mount Bracket (Mps)

    391695 / 391696 / 391715 / 391716 / 391717 2.3 Installation with Surface Mount Bracket (391695 Model) ① Remove the ceiling tile from the ceiling and ② Prepare the surface mount bracket. Pull the wires and cables cut a hole whose diameter is 30~40mm on for the system as below.

  • Page 23: Direct Installation On The Ceiling Mount Bracket(Mps)

    2.4 Direct Installation on the Ceiling (391696 model) ① ② For cable connection, remove the pre-defined hole To pass cables to upside of ceiling, please, make about 50~60mm hole on the ceiling panel. mark on the Rubber Gasket and locate the summit of the Plate Spring at the arrow mark as shown in the dotted circle.
  • Page 24 391695 / 391696 / 391715 / 391716 / 391717 Installation using In-Ceiling Mount Bracket (391696 model) ① Cut the panel of ceiling as shown bellow. ② Assemble Terminal Cover of camera to the In-Ceiling Mount Bracket as shown bellow. Hole Dimension(mm) ③...
  • Page 25 Installation using Ceiling Mount Bracket (391696 model) ① To pass cables to upside of ceiling, please make about ② Assemble Terminal Cover to Ceiling Mount Bracket 50~60mm hole on the ceiling panel and attach the with 3 screws. ( Do not use Rubber Gasket !) Ceiling mount bracket on it.

  • Page 26: Installation Using Wall Mount Bracket(Mps)

    391695 / 391696 / 391715 / 391716 / 391717 Installation using Wall Mount Bracket (391696 model) ① Install Wall Mount Bracket on wall. ② Assemble Terminal Cover to Wall Mount Bracket with 3 screws. ( Do not use Rubber Gasket !) Locate the summit of the Plate Spring at the arrow mark.

  • Page 27: Installation With Ceiling Mount Bracket(Mao/Mai)

    2.6 Installation with Ceiling Mount Bracket (391715/391716/391717 Models) ① ② Pull the wire(s) and cable(s) for the system as below. Remove the ceiling tile from the ceiling and cut a hole whose diameter is 30~40mm on the ceiling tile Wire the cable(s) to the ports. Insert the mounting to pass the wire(s) and cable(s) through to the upside hooks into the holes on the surface of the main body of the ceiling.

  • Page 28: Installation With Wall Mount Bracket(Mao/Mai)

    391695 / 391696 / 391715 / 391716 / 391717 2.7 Installation with Wall Mount Bracket (391715/391716/391717 Models) ① Make a hole whose diameter is 30~40mm on the ② Pull the wire(s) and cable(s) for the system as below. mounting surface to pass the wire(s) and cable(s) Wire the cable(s) to the ports.

  • Page 29: Wiring And Cabling

    2.8 Wiring and Cabling (391695/391715/391716/391717) POWER MAIN MONITOR AUDIO CABLE SPEAKER RS-485 CONTROLLER / DVR SENSOR I/O DOOR SENSOR SWITC Port Description Main Cable Port Pin Number (RJ45) Connector / Wire Color Signal Video + BNC Connector Video − RS-485 + RS-485 −...
  • Page 30 391695 / 391696 / 391715 / 391716 / 391717 Power Description Carefully check the voltage and current capacity of the rated power. The rated power is indicated in the back of main unit. Model Input Voltage Range Current Consumption 391695 0.8 A...
  • Page 31 Video Use BNC coaxial cable only. Alarm Input Internal +5V~12V IN COM+ IN 1- Sensor 1 Sensor 3 IN 3- Before connecting sensors, check driving voltages and output signal types of the sensors. Since output signal types of the sensors are divided into Open Collector type and Voltage Output type in general, the wiring must be done properly after considering those types.
  • Page 32 391695 / 391696 / 391715 / 391716 / 391717 Wiring and Cabling (391696 model) Power IrDA Sensor PWR(+) Door PWR(-) IN COM+ Switch VIDEO(+) Moinitor VIDEO(-) Sensor RS-485(+) RS-485(-) RELAY1 RELAY2 Light RS-485 Alarm Buzzer Controller / DVR Output Devices...
  • Page 33 Alarm I/O Connection Sensor Input Internal +5V~12V IN COM+ Sensor 1 Output IN 1- Sensor 4 Output IN 4- Before connecting sensors, check driving voltage and output signal type of the sensor. Since output signal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these typed.

  • Page 34: Operation

    391695 / 391696 / 391715 / 391716 / 391717 3 Operation 3.1 Check Points before Operation Before turning on the system, check if the wire(s) and cable(s) are connected properly. Check if the camera ID on the controller is properly selected. The camera ID must be identical to that of the target camera.

  • Page 35: Osd Menu

    3.3 OSD Menu Function With OSD menu, the system can be properly configured for each application. Entering into OSD Go Preset [95] 3.4 Reserved Presets (Hot Keys) Description Some Preset numbers are reserved to change some parameters without entering into OSD menu. Hot Keys Go Preset [95] : Entering into OSD menu...

  • Page 36: Preset

    391695 / 391696 / 391715 / 391716 / 391717 3.5 Preset Function MAX. 127 positions are programmable. The Preset number can be assigned from 1 to 128 except 95. Preset 95 is reserved for entering into OSD menu. Camera parameters such as White Balance, Auto Exposure and others can be set up independently and each preset can have its own parameter values independently from the other persets.

  • Page 37: Pattern

    3.7 Pattern Function This function is that the camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible. MAX. 4 Patterns are programmable and Maximum 1200 communication commands can be programmed in a pattern.

  • Page 38: Group

    391695 / 391696 / 391715 / 391716 / 391717 3.8 Group This function is that the camera memorizes the combination of Presets, Pattern and/or Function Swings sequently and runs Presets, Pattern and/or Swings repetitively. MAX. 8 sets of Group are programmable. Each group can have MAX. 20 actions which are the combination of Preset, Pattern and Swing.

  • Page 39: Other Functions

    3.9 Other Functions This setting defines a specific activity (Preset, Pattern, Swing and Group) to be Power Up Action performed in the event that the power to the camera is cycled. This function enables the user to resume, after turning on power, the last action being executed before turning off the power.

  • Page 40: Osd Display

    391695 / 391696 / 391715 / 391716 / 391717 3.10 OSD Display Action Title Preset Label LABEL12345 PRESET1 Alarm Information I:-2- O:1 Camera ID CAM 1 15/4/x1/N P/T/Z Information P/T/Z Information Displays the amount of pan from zero degree vertical, the amount of tilt from zero degree horizontal and current compass direction.

  • Page 41: Osd Menu

    4. OSD MENU 4.1 Quick Programming Guide The menu items with < > always have sub-menus. To go to submenus or make the cursor move to the right, press NEAR key. To go to the previous-upper level menus, press FAR key. To make a selection, press NEAR key To cancel a selection, press FAR key To move the cursor in the menu, use the joystick to the Up/Down direction or Left/Right direction.

  • Page 42: Display Setup

    391695 / 391696 / 391715 / 391716 / 391717 4.3 Display setup DISPLAY SETUP ------------------------ CAMERA ID PTZ INFORMATION AUTO ACTION TITLE AUTO PRESET LABEL AUTO ALARM I/O AUTO <SET NORTH DIRECTION> <PRIVACY ZONE> BACK EXIT Display setup allows you to program how labels are displayed on the monitor. In case of AUTO, the labels are displayed on the monitor when there are any changes in parameters.
  • Page 43 Compass Direction setup SET NORTH DIRECTION ------------------------ MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL Move the camera to a target position and press NEAR button to save the direction as North. The direction is the reference direction to assign other compass directions.

  • Page 44: Privacy Zone Mask Setup

    391695 / 391696 / 391715 / 391716 / 391717 4.4 Privacy Zone Mask Setup PRIVACY ZONE ------------------------ MASK NO UNDEFINED DISPLAY CLEAR MASK CANCEL <EDIT MASK> BACK EXIT Privacy Zone Mask allows the user to program 4 rectangulars that can not be viewed by the operator of the system. To protect privacy, MAX.
  • Page 45 Privacy Zone Mask Size Setup EDIT MASK 1 ------------------------ :ADJUST MASK WIDTH] :ADJUST MASK HEIGHT] [NEAR:SAVE /FAR:CANCEL] Adjusts the mask size. Use the joystick or the arrow buttons of your controller to adjust mask size. (Left/Right) Adjusts the mask width. (Up/Down) Adjusts the mask height.

  • Page 46: Camera Setup

    391695 / 391696 / 391715 / 391716 / 391717 4.5 Camera Setup ZOOM CAMERA SETUP ------------------------ FOCUS MODE SEMIAUTO DIGITAL ZOOM IMAGE FLIP SHARPNESS <WHITE BALANCE SETUP> <AUTO EXPOSURE SETUP> BACK EXIT Sets the general functions of zoom camera module.
  • Page 47 White Balance Setup WB SETUP - GLOBAL ------------------------ WB MODE AUTO ADJUST BLUE ADJUST BACK EXIT [AUTO/MANUAL] WB Mode Retains color balance over a color temperature range. In auto mode, this feature automatically processes the viewed image. In Manual mode, Red and Blue level can be set up manually.
  • Page 48 391695 / 391696 / 391715 / 391716 / 391717 Brightness [0~100] Adjusts the brightness of the images. Iris, The Shutter Speed and Gain are adjusted automatically in correspondence with each numeric value. [AUTO/MANUAL(0~100)] IRIS Sets Iris to operate automatically or at a user-defined level. If Iris is set to Auto, Iris has higher priority in adjusting AE and Shutter Speed is fixed.
  • Page 49 HLC (High Light Compensation) Setup ------------------------ LIMIT COLOR BACK EXIT [AUTO/MANUAL] Limit When there are too bright lights, this function blocks light sources on the images to have better images. For example, when there is a car coming to a camera at night, this function bocks car headlights to recognize its number plate.

  • Page 50: Motion Setup

    391695 / 391696 / 391715 / 391716 / 391717 4.6 Motion Setup MOTION SETUP ------------------------ MOTION LOCK PWR UP ACTION AUTO FLIP JOG MAX SPEED 120/SEC JOG DIRECTION INVERSE FRZ IN PRESET <PARKING ACTION SETUP> <ALARM INPUT SETUP> BACK EXIT Sets the general functions of Pan/Tilt motions.

  • Page 51: Parking Action Setup

    Parking Action Setup PARKING ACTION SETUP ------------------------ PARK ENABLE WAIT TIME 00:10:00 PARK ACTION HOME BACK EXIT This feature allows the camera to begin a specified action after a programmed time of inactivity. [ON/OFF] Park Enable If Park Enable is set to ON, the camera runs an assigned function automatically if there is no PTZ command during the programmed "Wait Time".
  • Page 52 391695 / 391696 / 391715 / 391716 / 391717 Hold Time [ENDLESS / 1~59 SEC. / 1~180 MIN.] Sets the time period for the action which is run by external sensor activation. After the time period passes, the action pre-defined in “ Post Action ” runs sequentially in succession to the action by external sensor activation.

  • Page 53: Preset Setup

    4.7 Preset Setup PRESET SETUP ------------------------ PRESET NO. CLR PRESET CANCEL <EDIT SCENE> <EDIT LABEL> LABEL123 RELAY OUT CAM ADJUST GLOBAL BACK EXIT Preset Number [1~128] Selects a preset number to set up. If a selected preset is already defined, the camera moves to the pre-defined position and preset parameters such as Label and CAM Adjust show on the monitor.
  • Page 54 391695 / 391696 / 391715 / 391716 / 391717 Preset Scene Setup EDIT SCENE - PRESET 1 ------------------------ MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL] ○ , 1 Use the Joystick to move the camera to a desired position. ○ , 2 Save the preset position by pressing NEAR key.
  • Page 55 1) With Left/Right/Up/Down of the joystick, move to a desired Alphabet or a desired number in the Alphanumeric set. To select a desired Alphabet or a desired number, press the NEAR key. ---------- 1234567890 ABCDEFGHIJ KLMNOPQRST UVWXYZabcd efghijklmn opqrstuvwx yz<>-/:. ---------- Space Char.
  • Page 56 391695 / 391696 / 391715 / 391716 / 391717 Relay Out Setup (391 696) RELAY OUT - PRESET 1 ------------------------ RELAY OUT 1 RELAY OUT 2 BACK EXIT Relay Out × [ON/OFF] Sets Relay Outputs for assigned preset.

  • Page 57: Swing Setup

    4.8 Swing Setup SWING SETUP ------------------------ SWING NO. 1ST POS. NOT USED 2ND POS. NOT USED SWING SPEED 30/SEC CLEAR SWING CANCEL RUN SWING BACK EXIT Swing [1~8] Number Selects a Swing number to edit. If the selected Swing is not defined, "NOT USED" is displayed in the 1st Position and the 2nd Position.

  • Page 58: Pattern Setup

    391695 / 391696 / 391715 / 391716 / 391717 4.9 Pattern Setup PATTERN SETUP ------------------------ PATTERN NO. UNDEFINED CLR PATTERN CANCEL RUN PATTERN <EDIT PATTERN> BACK EXIT Pattern Number [1~4 ] Selects a Pattern number to edit. If the selected pattern number is not defined, "UNDEFINED"...

  • Page 59: Group Setup

    4.10 Group Setup GROUP SETUP ------------------------ GROUP NO. UNDEFINED CLEAR GROUP CANCEL RUN GROUP <EDIT GROUP> BACK EXIT [1~8] Group Number Selects a Group number to edit. If the selected Group number is not defined, "UNDEFINED" will be displayed under the selected Group number.
  • Page 60 391695 / 391696 / 391715 / 391716 / 391717 EDIT GROUP 1 ------------------------ NO ACTION ### DWELL OPT ------------------------ 1 NONE 2 NONE 3 NONE 4 NONE 5 NONE ------------------------ SAVE :MOVE CURSOR] CANCEL [ :CHANGE VAL.] 3) Define Action, Dwell time and Option. Note that the dark rectangular is the cursor. Move the cursor Left / Right to select an item and move cursor Up / Down to change each parameter.
  • Page 61 EDIT GROUP 1 ------------------------ NO ACTION ### DWELL OPT ------------------------ 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE 5 NONE ------------------------ SAVE [NEAR:EDIT ACT] CANCEL [FAR :EDIT END] 5) After finishing editing a Action, press Near key to go to the previous-upper level menu (Step •). Move the cursor Up / Down ②...

  • Page 62: System Initialization

    391695 / 391696 / 391715 / 391716 / 391717 4.11 System Initialization SYSTEM INITIALIZE ------------------------ CLEAR ALL DATA CLR DISPLAY SET CLR CAMERA SET CLR MOTION SET CLR EDIT DATA REBOOT CAMERA REBOOT SYSTEM BACK EXIT Clear All Data Deletes all configuration data and the system is set to the factory default.

  • Page 63: Specifications

    Specifications CAMERA PART (391695/391715) Video Signal Format Image Sensor 1/4'' Interline Transfer CCD 795(H) × 596(V) 470K Total Pixels 752(H) × 582(V) 440K Effective Pixels Horizontal Resolution 500 TV Lines(Color), 570 TV Lines(B/W) Video Signal-to-Noise 50 dB (AGC Off) Zoom 10x Optical Zoom, 10x Digital Zoom Forcal Length F1.8, f=3.8~38 mm...
  • Page 64 391695 / 391696 / 391715 / 391716 / 391717 Specifications (391696) Model 391696 Video Signal System 1/4'' Super HAD color CCD 795(H) × 596(V) 470K Max. Pixels 752(H) × 582(V) 440K Effective Pixels Horizontal Res. 550 TV Line(Color), 680 TV Line(B/W)
  • Page 65 Specifications (391716 – 391717) CAMERA PART 391716 391717 Video Signal Format Image Sensor 1/4'' Interline Transfer CCD 795(H) × 596(V) 470 K Total Pixels 752(H) × 582(V) 440 K Effective Pixels Horizontal Resolution 550 TV Lines(Color), 680 TV Lines(B/W) Video Signal-to-Noise 50 dB (AGC Off) Optical Zoom Digital Zoom...
  • Page 66 391695 / 391696 / 391715 / 391716 / 391717 MECHANISM PART 360 ° (Endless) Movement Range 90 ° Tilt 360 ° /sec. Preset 0.05 ~ 360 ° /sec. (Proportional to Zoom) Speed 1~ 180 ° /sec. Swing Preset 127 Presets (Label, Independent Camera Parameter Setting) Pattern 4 Patterns [1200 Commands(Approx.
  • Page 67 MECHANICAL 391695 Model Surface Mount Ceiling Mount Wall Mount Dome Polycarbonate Material Internal Polycarbonate, ABS External Polycarbonate ∅ 107.5 mm / ∅ 4.2 ” Dome Size 132.4 × 129.5 mm 132.4 × 187.5 mm 213.2 × 207.5 mm Dimension Weight (kg) Approx 0.7 Approx 0.8 Approx 0.85 kg...

  • Page 68: Dimension

    391695 / 391696 / 391715 / 391716 / 391717 5.1 Dimension (391695 Model) Main Body Surface Mount Type 132.4 (MPS) 129.5 129.4 (MPL) 107.5 107.5 [Unit : mm]...
  • Page 69 Dimension (391696 Model) Main Body & Terminal Cover In-Ceiling Mount Bracket Hole Dimension(mm) Ceiling Mount Bracket Wall Mount Bracket 56.3 56.3 56.3 56.3 Unit (mm)
  • Page 70 391695 / 391696 / 391715 / 391716 / 391717 Dimension (391715 Model) Main Body Ceiling Mount Type 56.4 56.4 1.5" NPT 158.2 Wall Mount Type 118.6 274.5 [Unit : mm]...
  • Page 71 Dimension (391716/391717 Model) Main Body Ceiling Mount Type 56.4 56.4 1.5" NPT 158.2 Wall Mount Type 118.6 4- 8 [Unit : mm]...
