What's on your package?
One ISO-AD32H/AD32L series card
One companion ISA CD (V2.1 or later)
One Quick Start Guide(This document)
......................................................
2
Installing Windows Driver
Follow those steps:
1. Setup the Windows driver. You can get the driver from:
CD:\NAPDOS\ISA\ISO-AD32\
http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso-ad32/
(The Windows NT driver have support the Windows 2K and windows
XP/2003/Vista 32bit version.)
Windows driver only support windows 98/NT/2000 and
XP/2003/vista 32-bit versions.
ISO-AD32H/AD32L
Language
Version
Update
- 1 -
English
V1.0
Nov.2008
Advertisement
Table of Contents
Related Manuals for ICP DAS USA ISO-AD32H
Summary of Contents for ICP DAS USA ISO-AD32H
- Page 1 Version V1.0 Nov.2008 Update ……………………………………………… What’s on your package? One ISO-AD32H/AD32L series card One companion ISA CD (V2.1 or later) One Quick Start Guide(This document) ……………………………………………… Installing Windows Driver Follow those steps: 1. Setup the Windows driver. You can get the driver from: CD:\NAPDOS\ISA\ISO-AD32\ http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso-ad32/...
- Page 2 2. Click button to start installation. 3. Click button to install driver into the default folder. 4. Click button to continue installation. 5. Select “NO, I will restart my computer later” and then click button. ……………………………………………… I/O Base Address & IRQ Setting The base address is set from SW1 DIP switch on board: SW1 : BASE ADDRESS...
- Page 3 JP1: Analog Input Type Select / JP2: IRQ Channel Selection. IRQ3 IRQ4 IRQ5 IRQ6 IRQ7 Differential Single-ended IRQ9 IRQ10 (default) IRQ11 IRQ12 IRQ14 IRQ15 (default) ……………………………………………… Installing Hardware on PC Follow those steps: 1. Shut down and power off your computer 2.
- Page 4 ……………………………………………… Pin Assignments CN1:Single-Ended Analog Input / Differential Analog Input Connectors. Name Name Name Name AI16 AI0+ AI0- AI17 AI1+ AI1- AI18 AI2+ AI2- AI19 AI3+ AI3- AI20 AI4+ AI4- AI21 AI5+ AI5- AI22 AI6+ AI6- AI23 AI7+ AI7- AI24 AI8+ AI8- AI25...
- Page 5 ……………………………………………… Self-Test 1. Use DN-37(Optional) to connect the board CN1. 2. This example for Single-Ended Analog Input. AI0 connect to Analog GND (pin1 connect to pin36) AI8 connect to Analog GND (pin9 connect to pin36) AI16 connect to Analog GND (pin20 connect to pin36) AI24 connect to Analog GND (pin24 connect to pin36) Single-Ended DN-37 Wiring...
- Page 6 3. Run the ISO-AD32 sample program. Get the file from(Default): C:\DAQPro\ISO-AD32\DEMO 4. Check hardware, configuration setting and test Diag function. 1. Check SW1 (Depend on I/O Base Address) and JP1 Depend on JP1 2. Click this button to do Diag test. 5.
- Page 7 ……………………………………………… Additional Information ISO-AD32 Series Card Product page: http://www.icpdas.com/products/DAQ/pc_based/iso_ad32.htm DN-37(Optional) page: http://www.icpdas.com/products/DAQ/screw_terminal/dn_37.htm Documents: CD:\NAPDOS\ISA\ISO-AD32\manual http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso-ad32/manual/ Software: CD:\NAPDOS\ISA\ISO-AD32 http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso-ad32/ The ICP DAS Web Site http://www.icpdas.com Technical support Supplies and ordering information Ways to enhance your device Application story Contact Us Service@icpdas.com Copyright ©2008 by ICP DAS Co., Ltd.
