1
......................................................
What's on your package?
One ISO-C64 series card
One companion ISA CD (V2.1 or later)
One Quick Start Guide(This document)
2
......................................................
Installing Windows Driver
Follow those steps:
1. Setup the Windows driver. You can get the driver from:
CD:\NAPDOS\ISA\ISO\DLL\
http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso/dll/
2. Click
3. Click
4. Click
Select
5.
button to start installation.
"Next >"
button to install driver into the default folder.
"Next >"
button to continue installation.
"Install"
"NO, I will restart my computer later" and
Windows driver only support windows 98/NT/2000 and
XP/2003/vista 32-bit versions.
Language
Version
Update
- 1 -
ISO-C64
English
V1.3
Feb.2009
click
"Finish".
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ICP DAS USA ISO-C64
Summary of Contents for ICP DAS USA ISO-C64
- Page 1 Version V1.3 Update Feb.2009 ……………………………………………… What’s on your package? One ISO-C64 series card One companion ISA CD (V2.1 or later) One Quick Start Guide(This document) ……………………………………………… Installing Windows Driver Follow those steps: 1. Setup the Windows driver. You can get the driver from: CD:\NAPDOS\ISA\ISO\DLL\ http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso/dll/...
-
Page 2: I/O Base Address
……………………………………………… I/O Base Address The base address is set from SW1 DIP switch on board: * Default Base Address: 0x200 SW1: Base Address Address *0X200 0X208 ON OFF 1 2 3 4 5 6 0x210 ON OFF ON 0x218 ON OFF OFF 0x220 ON OFF ON 0x300... -
Page 3: Adding Hardware
7-10 The windows show to dialog box and Click the “OK” button to enter the device’s properties settings. 8. Modify the device properties 8-1 Enter the “ICPDAS ISO-P64/ISO-C64 Digital I/O Card Properties”. 8-2 Click the “ I/O Range ” and click the “Change setting” button to enter the “Edit Input/Output Range”. - Page 4 ……………………………………………… Pin Assignments Setting CON1: Pin assignment External External Power GND (-) Power GND (-) DO: 0-15 (-) DO: 16-31 (-) DO 0 DO 16 DO 1 DO 17 DO 2 DO 18 DO 3 DO 19 DO 4 DO 20 DO 5 DO 21 DO 6...
-
Page 5: Wiring Note
Wiring Note: Recommend: It is necessary to connect a diode in the output ※ end as means of preventing damage from the counter emf. If your External Device is inductive Load, Ex. Relay… To prevent the board damaged forever by overload, the GND pins (CON1: pin 1/20, CON2: pin 1/ 20) all must be connected with GND of External Power. - Page 6 ……………………………………………… Self-Test Prepare for device: DN-37(Optional) wiring terminal board. Exterior power supply device. For example: DP-665(Optional) Use DN-37 to connect the board CON1. External +24 V connect to external CON1.DO:0-15(+) and GND connect to CON1. DO:0-15(-). (External +24 V connect to Pin18, External GND connect to Pin1) Use output LED to connect the CON1.DO1 and DO:0-15(+).
- Page 7 5. Run the ISO-C64 sample program. Get the file from(Default): C:\DAQPro\ISO_WinXXX\Demo\ 6. Check number of the ISO-C64, and test DO function. 1. The one ISO-C64 had 3. Click this successfully button to do installed to PC. DO test. 2. Select the...
-
Page 8: Additional Information
……………………………………………… Additional Information ISO-C64 Series Card Product page: http://www.icpdas.com/products/DAQ/pc_based/iso_c64.htm DN-37(Optional) page: http://www.icpdas.com/products/DAQ/screw_terminal/dn_37.htm DP-665(Optional) page: http://www.icpdas.com/products/Accessories/power_supply/dp-665.htm Documents: CD:\NAPDOS\ISA\ISO\manual http://ftp.icpdas.com/pub/cd/iocard/isa/napdos/isa/iso/manual/ Software: CD:\NAPDOS\ISA\ISO http://www.icpdas.com/download/isa/iso/index.htm The ICP DAS Web Site http://www.icpdas.com Technical support Supplies and ordering information Ways to enhance your device Application story Contact Us Service@icpdas.com...
