Build The Network Topology; Log In To The Eap - TP-Link EAP110 User Manual

1.2 Build the Network Topology

To manage the EAPs in Standalone mode, refer to the following topology.
PC
IP: 192.168.0.100
• The router is the gateway of the network, and devices in the LAN surf the internet via
the router. At the same time, the router acts as a DHCP server to assign dynamic IP
addresses to the EAPs and clients.
• The layer 2 switch is connected to the LAN interface of the router.
• The PC and the EAPs are all connected to the layer 2 switch. Since the PC and the EAPs
are in the same network segment, the PC can log in to the web pages of the EAPs and
manage them.

1.3 Log in to the EAP

There are two methods to log in to the EAP. You can choose one as you like:
Domain Name

Ntte

EAP320 and EAP330 are not currently available for login via domain name.
Switch
EAP
and Log in via the IP Address of the EAP
Router (DHCP Server)
LAN: 192.168.0.1
EAP
Clients
.
6
Internet
Log in via the
