Operating Manual
Requests for Daily Care and Maintenance
This machine is a precision machine equipped with extremely fine mechanisms. Especially, the nozzle sur-
face of the heads from which the ink is discharged is affected even by a slightest attachment of dust or paper
powder and the proper printing results could not be obtained. With a view to using this machine in a better
condition, we would like to recommend performing the following care and maintenance on daily basis.
1. When to care
When to care
Once a day
(at the end of the daily work)
Once a week
(at the end of the work on
weekend)
Once a week or two weeks
Once a year
When the Machine Is Not Used
for a Long Time
Tools required for maintenance
• Cleaning stick (SPC-0527)
• Cleaning liquid 03 maintenance kit (ML003-Z-K1)
• Cotton swab
• Gloves
• Soft fabric
Inkjet printer Tx500-1800B
Surroundings of the heads
Capping station
Wiper
Wiper blade
Exterior
Waste ink tank
Cleaning the float sensor part of external ink supply unit
Replacing the carriage filter
Replacing the ink filter at main body side
Replacing the ink filter of external ink supply unit
Replacing filter element of filter for vacuum
Perform "Storage Wash"
1
What to care
Reference Page
P.2
P.4
P.5
P.6
P.8
P.8
P.9
P.10
P.14
P.16
P.15
P.19
