Sea Tel 6012-12w VSAT Antenna System
Installation Manual
This technical data is subject to US Government export control in accordance with the
Export Administration Regulations. Export of this data to any foreign country, or
disclosure of this data to a Non-US person, may be a violation of Federal law.
Sea Tel, Inc.
(trading as Cobham SATCOM)
4030 Nelson Avenue
Concord, CA 94520
Tel: +1 (925) 798-7979
Fax: +1 (925) 798-7986
Web:
http://www.cobham.com/satcom
November 3, 2016
EAR Controlled - ECCN EAR99
EAR Controlled - ECCN EAR99
Thrane & Thrane A/S
(trading as Cobham SATCOM)
Lundtoftegaardsvej 93 D, 2800 Kgs.
Lyngby, Denmark
Tel: +45 3955 8800
Fax: +45 3955 8888
Email:
Document. No. 99-147353-A1

Advertisement

Table of Contents
loading

Related Manuals for Sea Tel 6012-12w

Summary of Contents for Sea Tel 6012-12w

  • Page 1 Sea Tel 6012-12w VSAT Antenna System Installation Manual EAR Controlled - ECCN EAR99 This technical data is subject to US Government export control in accordance with the Export Administration Regulations. Export of this data to any foreign country, or disclosure of this data to a Non-US person, may be a violation of Federal law.
  • Page 2 Copyright © 2016 Sea Tel Inc All Rights Reserved. The information contained in this document is proprietary to Sea Tel, Inc.. This document may not be reproduced or distributed in any form without prior written consent of Sea Tel, Inc. The information in this document is subject to change without notice. Sea Tel Inc, is also doing business as Cobham SATCOM –...
  • Page 3 Fax:+1 (925) 288-1420 R&TTE Declaration of Conformity Sea Tel Inc. declares under our sole responsibility that the products identified below are in compliance with the requirements of: DIRECTIVE 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on Radio equipment and Telecommunication Terminal Equipment and the mutual recognition of their conformity.
  • Page 4 2009 version of FCC 47 C.F.R. § 25.222. Sea Tel hereby declares that the antennas listed below will meet the off-axis EIRP spectral density requirements of § 25.222 (a)(1)(i) with an N value of 1, when the following Input Power spectral density limitations are met: *0.6 Meter Ku Band, Models 2406 and USAT-24 are limited to...

  • Page 5: Table Of Contents

    Table of Contents 6012-12W Installation Manual 1. SERIES 12 KU-BAND SYSTEM CONFIGURATION(S) ................. 1.1. S 12 B ....................ERIES ASIC YSTEM NFORMATION 1.2. S ........................... YSTEM ABLES 1.3. O ....................... THER NPUTS TO THE YSTEM 1.4. S 09MK3 12 K ..........
  • Page 6 6012-12W Installation Manual Table of Contents 3.7.1. General Cautions & Warnings ....................3.8. C .................... ONNECTING THE ELOW ECKS QUIPMENT 3.8.1. Connecting the BDE AC Power Cables ..................3.8.2. Connecting the ADE-BDE Coax Cables ..................3.8.3. Media Xchange Point™ (MXP) Connections ................
  • Page 7 OWER 13.2.1. 13-5 Removing the AZ Shipping/Stow Restraint ................13.2.2. Removing the EL Shipping/Stow Restraint ................13-6 13.2.3. Removing the CL Shipping/Stow Restraint ................13-8 14. 6012-12W TECHNICAL SPECIFICATIONS ..................14-2 14.1. A ........................14-2 BOVE ECKS QUIPMENT 14.2. B ........................
  • Page 8 6012-12W Installation Manual Table of Contents This Page Intentionally Left Blank viii EAR Controlled - ECCN EAR99...

  • Page 9: Series 12 Ku-Band System Configuration(S)

    Series 12 Ku-Band System Configuration(s) 6012-12W Installation Manual Series 12 Ku-Band System Configuration(s) The Series 12 Ku-Band Stabilized Antenna system is to be used for Transmit/Receive (TX/RX) satellite communications. It is comprised of two major groups of equipment: the Above Decks Equipment (ADE) and the Below Decks Equipment (BDE).
  • Page 10 6012-12W Installation Manual Series 12 Ku-Band System Configuration(s) 1.4. Simplified Block Diagram of a Series 09MK3 or 12 Ku-Band System Your Series 12 Ku-Band TXRX system consists of two major groups of equipment: an above-decks group and a below-decks group. Each group is comprised of, but is not limited to, the items listed below. All equipment comprising the Above Decks is incorporated inside the radome assembly and is integrated into a single operational entity.

  • Page 11: Dual Antenna Configuration

    These each have standardized language incorporated into their (iDirect, Comtech & STM) modems which communicates automatic beam switching settings from their options file to the Sea Tel ACU(s). This provides the network a means of controlling automatic beam switching by the settings in the options file in the remote modem.
  • Page 12 6012-12W Installation Manual Series 12 Ku-Band System Configuration(s) To be compliant with these FCC requirements, the “Transmit Mute” output of the Sea Tel below decks controller must be connected to the “Mute Input” of the satellite modem via serial or via an Ethernet connection to the modem.
  • Page 13 Series 12 Ku-Band System Configuration(s) 6012-12W Installation Manual This Page Intentionally Left Blank EAR Controlled - ECCN EAR99...

  • Page 14: Site Survey

    Site Survey 6012-12W Installation Manual Site Survey There are three objective of the site survey. The first is to find the best place to mount the antenna and the BDE. The second is to identify the length and routing of the cables and any other items or materials that are required to install the system.

  • Page 15: Mounting Foundation

    The following should be taken into account when choosing the height of a mounting support stand: The height of the pedestal should be kept as short as possible, taking into account recommendations given in other Sea Tel Guidelines. 2. The minimum height of the pedestal above a flat deck or platform to allow access into the radome for maintenance should be 0.6 meters (24 inches).

  • Page 16: Mounting Height

    2.5. Mast Configurations Sea Tel recommends mounting the ADE in a location that has both a clear line-of-sight to the target satellites in all potential azimuth/elevation ranges and sufficient support against vibration excitement. If possible, mounting the ADE pedestal directly to ship deckhouse structures or other box stiffened structures is preferred.

  • Page 17: Vertical Masts

    6012-12W Installation Manual Site Survey 2.5.1. Vertical Masts Vertical masts are a very ancient and common mast design. In essence, it is the mast derived from the sailing mast and adapted for mounting the ever-increasing array of antennae which ships need to communicate with the world.

  • Page 18: Truss Mast

    50 millimeters and thickness by 2 millimeters. Sea Tel does not have a recommended arrangement for a truss mast – the variability of truss mast designs means that each installation needs to be evaluated separately.

  • Page 19: Ade/Bde Coaxial Cables

    In as much as is possible, don’t lay the coaxes on power cables. Don’t lay the coaxes on, or directly beside, the cables from a second Sea Tel antenna, Inmarsat antenna and/or GPS antenna that are also passing L-band frequencies. Don’t lay the coaxes on, or directly beside, radar cables that may inject pulse repetition noise –as error bits - into your cables.

  • Page 20: Acu Power Cable/Outlet

    Site Survey 6012-12W Installation Manual The power cable shall be continuous from the closest circuit breaker to the ADE connections within the radome. The power circuits shall be arranged so that ‘active,’ ‘common’ and ‘neutral’ (ground) legs are all made or broken simultaneously. All circuit legs shall be carried in the same cable jacket.

  • Page 21: Installation

    Installation 6012-12W Installation Manual Installation Your antenna pedestal comes completely assembled in its radome. This section contains instructions for unpacking, final assembling and installing of the equipment. It is highly recommended that trained technicians install the system. The installation instructions for your system are below.

  • Page 22: Installing The Ade

    6012-12W Installation Manual Installation 3.3. Installing the ADE The antenna pedestal is shipped completely assembled in its radome. Please refer to the entire Site Survey chapter of this manual. Base Hatch Access - Mounting the radome directly on the deck or platform prevents access to the hatch in the base of the radome unless an opening is designed into the mounting surface to allow such entry.

  • Page 23: Install 76" Radome To Mounting Deck

    Installation 6012-12W Installation Manual Attach shackles and four part web lifting sling arrangement to the eyebolts. Attach a suitable length tagline to one of the eyebolts. 8. After hoisted into place the lifting eyes are to be removed and replaced with the...

  • Page 24: Grounding The Pedestal

    Braid is the conductor of choice where flexibility is required. Sea Tel uses braid to cross axes of the antenna pedestal and to connect various subassemblies together.

  • Page 25: Removing The Az Shipping/Stow Restraint

    Installation 6012-12W Installation Manual 3.5.1. Removing the AZ Shipping/Stow Restraint The AZ shipping/stow restraint is formed by a pin bolt that is lowered into a channel in a stowage block on the upper plate of the pedestal (as shown). 2. To un-stow the antenna, remove the pin bolt from the LOCK position.
  • Page 26 6012-12W Installation Manual Installation Pin inserted into Elevation Driven Sprocket Elevation Driven Sprocket To un-restrain the elevation axis of the antenna, unthread the two hex nuts. Using a ¾” open end wrench, remove the hex nuts and washer from the stow pin-bolt.

  • Page 27: Removing The Cl Shipping/Stow Restraint

    Installation 6012-12W Installation Manual 8. Tighten the hex nut to prevent the hardware from loosening while in the un-stowed configuration. Verify that the antenna rotates freely through its full elevation range of motion. 3.5.3. Removing the CL Shipping/Stow Restraint The CL shipping/stow restraint is...

  • Page 28: Connecting The Above Decks Equipment

    Assure that the Gyro Compass output is turned OFF when handling and connecting wiring to the MXP. CAUTION - Allow only an authorized dealer to install or service the Sea Tel System components. Unauthorized installation or service can be dangerous and may invalidate the warranty.

  • Page 29: Connecting The Bde Ac Power Cables

    Installation 6012-12W Installation Manual 3.8.1. Connecting the BDE AC Power Cables Connect the AC Power cables that supply power to the Below Decks Equipment (MXP, BDE Fiber Enclosure, TXRX Dual Antenna Arbitrator, Satellite Modem, phone, fax, computer and all other equipment) to an outlet strip fed from a suitably rated breaker or UPS.
  • Page 30 6012-12W Installation Manual Installation Pin 5 Pin6 Pin 7 Pin 8 TX+ NMEA Pin 9 +12 VDC (125ma MAX) If your NMEA 0183 Gyro Compass outputs RS-422: Connect its’ TX+ output to J10 pin 1 (RX+)  Connect its’ TX- output to J10 pin 2 (RX-) If your NMEA 0183 Gyro Compass outputs RS-232:...

  • Page 31: Other Bde Connections

    Installation 6012-12W Installation Manual J15 NMEA 2000 - NMEA 2000 I/O connection. RESERVED FOR FUTURE USE 3.8.4. Other BDE connections Connect your other Below Decks Equipment (ie, telephone, fax machine and computer equipment) to complete your configuration. 3.9. Final Checks 3.9.1.
  • Page 32 6012-12W Installation Manual Installation 3.10. Setup - Media Xchange Point™ (MXP) Now that you have installed the hardware, you will need to setup, calibrate and commission the antenna. You may also need to load/update the modem option file, which is not part of the scope of this manual, contact the airtime provider NOC for guidance.
  • Page 33 Installation 6012-12W Installation Manual This Page Intentionally Left Blank 3-13 EAR Controlled - ECCN EAR99...

  • Page 34: Configuring A Computer For The Mxp

    Configuring a Computer for the MXP 6012-12W Installation Manual Configuring a Computer for the MXP The first thing you need to do is to configure your computer so that it will display the MXP screens. Follow these instructions to accomplish that.
  • Page 35 6012-12W Installation Manual Configuring a Computer for the MXP 4. From your computer desktop, click the Control Panel button. 5. Click on “View network status and tasks”. 6. Click “Change adapter settings”. Click on “Local Area Connection.” EAR Controlled - ECCN EAR99...
  • Page 36 Configuring a Computer for the MXP 6012-12W Installation Manual 8. Click on “Properties”. 9. Click on “Internet Protocol Version 4 (IPv4)”. 10. Click on “Use the following IP address: 11. In the IP Address boxes, enter “10.1.1.102” (This is for the IP address of your computer).
  • Page 37 6012-12W Installation Manual Configuring a Computer for the MXP 12. On the second line, enter Subnet Mask of “255.255.255.0”. 13. Then click the “OK” button. 14. Back at the Local Area Connection Properties screen, click the “OK” button. 15. Click the “Close” button.
  • Page 38 Configuring a Computer for the MXP 6012-12W Installation Manual 17. Open your browser, and enter the URL: “10.1.1.100”. 18. At the log in screen enter the user name & password. User name and password are case sensitive. Dealer password seatel3...
  • Page 39 6012-12W Installation Manual Configuring a Computer for the MXP This Page Intentionally Left Blank EAR Controlled - ECCN EAR99...
  • Page 40 Setup – Ship’s Gyro Compass 6012-12W Installation Manual Setup – Ship’s Gyro Compass The Ships Gyro Compass connection provides true heading (heading of the ship relative to true North) input to the system. This allows the ICU to target the antenna to a “true” Azimuth position to acquire any desired satellite.
  • Page 41 6012-12W Installation Manual Setup – Ship’s Gyro Compass 4. Click Save, at the bottom left area of the screen. 5.2. If there is NO Ships Gyro Compass Without heading input to the system the MXP will NOT be able to easily target, or stay stabilized ON, a “true”...
  • Page 42 Setup – Ship’s Gyro Compass 6012-12W Installation Manual Turn on SAT REF Mode. (It must be turned on.) This combination of settings will cause “No Gyro” Search pattern to be use to find the desired satellite (refer to the setup – Searching chapter).
  • Page 43 6012-12W Installation Manual Setup – Ship’s Gyro Compass This Page Intentionally Left Blank EAR Controlled - ECCN EAR99...

  • Page 44: Setup – Azimuth Trim

    Setup – Azimuth Trim 6012-12W Installation Manual Setup – Azimuth Trim Beginning in IMA software version 1.05, calibrating the targeting of your antenna is much easier. This is accomplished improving Sky Search and changing the way that Azimuth Trim works so that the need for Home Flag Offset is eliminated.
  • Page 45 6012-12W Installation Manual Setup – Azimuth Trim instruction for AUTO TRIM to optimize the targeting of the antenna. EAR Controlled - ECCN EAR99...

  • Page 46: Setup – Blockage & Rf Radiation Hazard Zones

    The Blockage Zones function inhibits the antenna from transmitting within certain pre-set zones. This is typically some structure of the ship that prevents satellite signal from getting to the Sea Tel antenna when the ship is at headings that put that structure in-between the satellite and the satellite antenna, However, it can also be used as an RF Radiation Hazard zone.
  • Page 47 6012-12W Installation Manual Setup – Blockage & RF Radiation Hazard Zones ZONE 1 named “Fwd Deckhouse” begins (REL Start) at 334 degrees Relative and ends (REL Stop) at 026 degrees Relative. Enter REL Start value of 334.0 and REL Stop value of 26.0. In this case the mast height only causes blockage up to an elevation of 40 degrees, so we set EL to 40.0.
  • Page 48 Setup – Blockage & RF Radiation Hazard Zones 6012-12W Installation Manual 5. Likewise, for Elevation, you need only to enter the elevation angle, below which you want the transmitter inhibited (blocked). 6. Repeat steps 2-5 to describe up to 4 blockage zones.
  • Page 49 6012-12W Installation Manual Setup – Blockage & RF Radiation Hazard Zones This Page Intentionally Left Blank EAR Controlled - ECCN EAR99...

  • Page 50: Configuring The Satellite Modem Interface

    Configuring The Satellite Modem Interface. 6012-12W Installation Manual Configuring The Satellite Modem Interface. The configuration setup of an integrated satellite modem to the MXP is accomplished via the Communication Interface Page (Configuration>Interfaces link on the navigational panel on the left hand side of the screen). In order to access this page, the user must be logged in as either “Dealer”...

  • Page 51: Modem Type Setting

    6012-12W Installation Manual Configuring The Satellite Modem Interface. Use: In a dual reflector based antenna system, the “Reflector” selection defines which reflector the modem configuration applies to. Selection Type: Mutually Exclusive Radio Buttons Options: Primary or Secondary Notes: In the current Series 12 antennas this setting should always be set to PRIMARY.

  • Page 52: Modem I/O – Custom Settings

    Configuring The Satellite Modem Interface. 6012-12W Installation Manual 8.1.4. Modem I/O – Custom Settings Use: The individual Modem I/O selections allow the user to manually define the expected driver (output) and detector (input) circuit(s) as well as positive satellite ID functionality between the MXP and the satellite modem.
  • Page 53 6012-12W Installation Manual Configuring The Satellite Modem Interface. Failure to do so may result in a false Rx Lock trigger when the applicable modem interface cable is removed for any reason. 8.1.4.3. Modem I/O – Lock Input - Voltage Use: The Modem I/O Lock Input Voltage selection defines the nominal voltage range for the hard lined wire input for indication of Positive Satellite ID (RX Network Lock indication).

  • Page 54: Q Uick R Eference

    Configuring The Satellite Modem Interface. 6012-12W Installation Manual However there are some conditions where this may not be true, as is the case of the antenna being pointed at a pre-defined “Radiation Hazard Zone”, which discussed in detail within another chapter of this manual, is programmed in as a Blockage Zone, thus the name Block Output.
  • Page 55 6012-12W Installation Manual Configuring The Satellite Modem Interface. This Page Intentionally Left Blank EAR Controlled - ECCN EAR99...

  • Page 56: Setup – Targeting

    Setup – Targeting 6012-12W Installation Manual Setup – Targeting Optimize the targeting of the antenna to track on or near a desired satellite (within +/-1 degree. 9.1. AUTO TRIM The Auto Trim function will automatically calculate and set the required Azimuth and Elevation trim offset parameters required to properly calibrate the antennas display to the mechanical angle of the antenna itself, while peaked ON satellite.
  • Page 57 6012-12W Installation Manual Setup – Targeting Click SAVE 9.2. Manually Optimizing Targeting First, assure that all of your Ship & Satellite settings in the MXP are correct. 2. Access the Satellite Search screen Target the desired satellite by selecting it from the drop down list.
  • Page 58 Setup – Targeting 6012-12W Installation Manual 9. Access the Reflector Configuration page. 10. Enter the Elevation Trim in the EL field. 11. Enter the Azimuth Trim in the AZ field. 12. Click Save. 13. Re-target the satellite several times to verify that targeting is now driving the antenna to a position that is within +/- 1.0 degrees of...
  • Page 59 6012-12W Installation Manual Setup – Targeting This Page Intentionally Left Blank EAR Controlled - ECCN EAR99...

  • Page 60: Setup – Satellite Configuration

    The satellite selection will in turn control the hardware on the antenna pedestal to select the correct TX & RX hardware and the correct tracking settings. Sea Tel provides quad-band LNBs as standard on the Ku-Band feed assemblies. 10.1.

  • Page 61: Sky Search Pattern

    6012-12W Installation Manual Setup – Satellite Configuration If the desired signal is found (AND network lock is achieved in the satellite modem) at this position, or anywhere within the search pattern, the MXP will terminate search and go into Tracking mode. If the desired signal is not found the MXP will wait SEARCH DELAY, then target the antenna to start point shown in the graphic above and begin the search pattern again.
  • Page 62 The satellite selection will in turn control the hardware on the antenna pedestal to select the correct TX & RX hardware and the correct tracking settings. Sea Tel provides quad-band LNBs as standard on the Series 12 Ku-Band antennas. Access the Satellite Configuration screen.
  • Page 63 6012-12W Installation Manual Setup – Satellite Configuration 10. Select the desired type of search pattern to use for this satellite. 11. Select desired TX Polarity from the drop down menu. 12. Select desired Band from its drop down menu. 13. Assure that reflector is set to “Primary”.

  • Page 64: Quick Start Operation

    Quick Start Operation 6012-12W Installation Manual Quick Start Operation If your system has been set up correctly, and if the ship has not moved since the system was used last, the system should automatically acquire the satellite from a cold (power-up) start. Once the satellite has been acquired, the modem then should achieve lock and you should be able to use the system.

  • Page 65: I F Satellite Signal Is Found But Network Lock Is

    6012-12W Installation Manual Quick Start Operation search pattern followed by retarget). 5. Check Latitude, Longitude and Heading. These should be correct, but may be updated if necessary. 6. Access the System Status screen. Find the Latitude, Longitude (under Ship) and Heading (in the banner) displayed values.
  • Page 66 Quick Start Operation 6012-12W Installation Manual antenna will resume its search pattern. If the system does not acquire the correct satellite within the prescribed search pattern, the antenna will retarget and the cycle will repeat (Search Delay timeout, conduct search pattern followed by retarget).

  • Page 67: T O T Arget A Different Satellite

    6012-12W Installation Manual Quick Start Operation 11.4. To Target a different satellite To target a different satellite go to the Satellite Search Auto screen and select the desired satellite from the drop down list. 2. When you make that selection you will see the temporary message: Acquiring Satellite Signal…Please Wait...

  • Page 68: Optimizing Cross-Pol Isolation

    Optimizing Cross-Pol Isolation 6012-12W Installation Manual Optimizing Cross-Pol Isolation Now that all of the other setup items have been checked and changed as necessary, it is time to contact the NOC to arrange for cross-pol isolation testing and whatever other commissioning the NOC asks for. Read this procedure thoroughly before you are asked to begin.
  • Page 69 6012-12W Installation Manual Optimizing Cross-Pol Isolation 6. Access the Reflector Configuration screen. Change the “Linear Offset” value by the amount of difference recorded in step 4. Examples: Skew was 0.0, you increased it to 2.5 to optimize TX polarization. You set Skew back to zero and go to the Reflector Configuration screen where you find Linear Offset to be 0.0, so you increase...
  • Page 70 Optimizing Cross-Pol Isolation 6012-12W Installation Manual This Page Intentionally Left Blank 12-3 EAR Controlled - ECCN EAR99...
  • Page 71 Optimizing Cross-Pol Isolation 6012-12W Installation Manual This Page Intentionally Left Blank 12-1 EAR Controlled - ECCN EAR99...

  • Page 72: Installing The Az Shipping/Stow Restraint

    6012-12W Installation Manual Stowing the Antenna Stowing the Antenna This antenna must be properly stowed if the ship will be underway while AC power to the Above Decks Equipment (ADE) is de-energized. Failure to do so may void your warranty.

  • Page 73: Installing The El Shipping/Stow Restraint

    Stowing the Antenna 6012-12W Installation Manual 13.1.2. Installing the EL Shipping/Stow Restraint The EL shipping/stow restraint is formed by a stow pin-bolt mounted through a bracket and is engaged into a hole/slot in the elevation driven sprocket when the dish is at zenith (90 degrees elevation).

  • Page 74: Installing The Cl Shipping/Stow Restraint

    6012-12W Installation Manual Stowing the Antenna 5. Remove the washer from the stow pin-bolt and unthread the hex nut from the bolt. 6. Put one of the washers onto the stow pin- bolt and insert it into the bracket toward the elevation driven sprocket.

  • Page 75: Removing The Shipping/Stow Restraints Prior To Power-Up

    Stowing the Antenna 6012-12W Installation Manual If not already removed, remove an adjustable bumper by removing the bottom nut from one end of the locking bar. If not already loosened, loosen the top nut up toward the rubber bumper. 4. Insert vacant end of the locking bar through the opening under the cross-level beam.

  • Page 76: Removing The El Shipping/Stow Restraint

    6012-12W Installation Manual Stowing the Antenna Install the pin bolt into the STOW hole and tighten. This assures that it does not get lost and will be ready for re-use if the antenna needs to be stowed again at a later date.
  • Page 77 Stowing the Antenna 6012-12W Installation Manual To un-restrain the elevation axis of the antenna, unthread the two hex nuts. Using a ¾” open end wrench, remove the hex nuts and washer from the stow pin-bolt. 4. Remove the stow pin-bolt from the bracket.

  • Page 78: Removing The Cl Shipping/Stow Restraint

    6012-12W Installation Manual Stowing the Antenna 8. Tighten the hex nut to prevent the hardware from loosening while in the un-stowed configuration. Verify that the antenna rotates freely through its full elevation range of motion. 13.2.3. Removing the CL Shipping/Stow Restraint...
  • Page 79 Stowing the Antenna 6012-12W Installation Manual 5. Extract the locking bar from the underside of the cross-level beam and retain these parts for later re-use if it becomes necessary to stow the antenna. 6. Verify that the antenna rotates (tilts...

  • Page 80: 2-12W Technical Specifications

    6012-12W Installation Manual 6012-12w Technical Specifications 6012-12w Technical Specifications The specifications of your antenna system are below. 14.1. Above Decks Equipment System Weight (ADE) Weight 208 kg / 460 lbs (76 in radome) Stabilized Antenna Pedestal Assembly Type Three-axis (Level, Cross Level and Azimuth)
  • Page 81 +/- 20° at 8 second period Pitch 10° Fixed Relative Azimuth (Heading) 0, 45 and 90° with respect to roll input Mounting Height Sea Tel recommends you do not exceed tangential accelerations of 0.5G (See below chart) Antenna Reflector Ku-Band Type Spun Aluminum Diameter 1.47 m / 58"...
  • Page 82 6012-12W Installation Manual 6012-12w Technical Specifications SSPB Gilat 12w Output Flange WR-75 Input Connector Type F RF Input Frequency Range 950 to 1450 MHz RF Output Frequency Range 14.0-14.5 GHz RF Output VSWR 2.5:1 max RF Pout@ 1 dB GCP...
  • Page 83 6012-12w Technical Specifications 6012-12W Installation Manual Integrated Control Unit (ICU) Connectors SMA (F) - RXIF Input from LNB 1 (Cross-Pol) SMA (F) - RXIF Input from LNB 2 (Co-Pol) SMA (F) - RXIF Output To Rotary Joint J4 B/A Ethernet - RJ45 Serial M&C - A=Radio M&C, B=Pass through Mini USB Antenna M&C...
  • Page 84 6012-12W Installation Manual 6012-12w Technical Specifications Motor Driver Enclosure Connectors Drive DA-15P Home DE-9S DA-15S DA-15S DA-15S Status LEDs CL Drive EL Drive Az Drive MDE Status Interface Connections Connection Dual Channel Rotary Joint Power Requirements 85-264 VAC, 47-63Hz, single phase (MAX below = brake release, pedestal drive and BUC drive).
  • Page 85 6012-12w Technical Specifications 6012-12W Installation Manual Mechanical Conditions Systematic Vibration Amplitude (single peak) 5.0 millimeters Acceleration 2.0 G (20m/s2) Frequency Range 1Hz - 150Hz Shock (Transient Vibration) Response Spectrum - II - III Peak Accel., m/s2 100 - 300 - 500...

  • Page 86: Below Decks Equipment

    6012-12W Installation Manual 6012-12w Technical Specifications 14.2. Below Decks Equipment Media Xchange Point (MXP) Standard 19 Inch Rack mount One Unit High Physical Dimensions 17 X 17 X 1.75 (Inches)/ 43.18 x 43.18 x 4.45 (cm) Input Voltage 85-264 VAC, 47-63Hz, single phase, 110 Watts Weight 6.6lbs/ 3.0 kgs...
  • Page 87 6012-12w Technical Specifications 6012-12W Installation Manual Synchro Interface Connectors 5 screw terminal connections (Plug-In) Input Voltage Level 36-110 VDC, 400 or 60 Hz Synchro Ratios 1:1, 36:1, 90 or 180:1 and 360:1 Impedance 1M ohm SBS Interface Connectors 4 screw terminal connections (Plug-In)

  • Page 88: Regulatory Compliance

    6012-12W Installation Manual 6012-12w Technical Specifications Dry Contact Output Sets (SW3 A-B & SW4 A-B ) Switched outputs 4.7K pull up or Pull Down Current handling Current sink of 0.5 amps max. No Alarm State Normally Open Alarm State Contact closure...

  • Page 89: Cables

    14.4.1. Antenna L-Band IF Coax Cables (Customer Furnished) Due to the loss across the length of the RF coaxes at L-Band, Sea Tel recommends the following 50 ohm coax cable types (and their equivalent conductor size) for our standard pedestal installations. Type N...

  • Page 90: Gyro Compass Interface Cable (Customer Furnished)

    6012-12W Installation Manual 6012-12w Technical Specifications 14.4.4. Gyro Compass Interface Cable (Customer Furnished) Type: Multi-conductor, Shielded Number of wires 4 Conductors for Step-By-Step Gyro, 5 Conductors for Synchro Wire Gauge: see Multi-conductor Cables spec above Insulation: 600 VAC 14-12 EAR Controlled - ECCN EAR99...
  • Page 91 6012-12w Technical Specifications 6012-12W Installation Manual This Page Intentionally Left Blank 14-13 EAR Controlled - ECCN EAR99...
  • Page 92 6012-12W Installation Manual 6012-12w Technical Specifications This Page Intentionally Left Blank 14-14 EAR Controlled - ECCN EAR99...

  • Page 93: Drawings

    DRAWINGS 6012-12W Installation Manual DRAWINGS 15.1. 6012-12 Model Specific Drawings Drawing Title 40-300068 System, 6012-12 in 76” Radome 15-3 DL-000831-A System Block Diagram, 6012-12, Ku-Band 15-5 93-148719-A Antenna Schematic, 6012-12 15-10 137389_A2 Pedestal Schematic, xx12 15-11 62-146645 General Assembly 6012-12...
  • Page 94 6012-12W Installation Manual DRAWINGS This Page Intentionally Left Blank 15-2 EAR Controlled - ECCN EAR99...
  • Page 95 (NOT SHOWN) ECO-00008545 1 ea 137387-1 CUSTOMER DOC PACKET, SERIES 12 KU-BAND (NOT SHOWN) ECO-00008546 1 ea 124766-1 DECAL KIT, 66-81 IN RADOME, SEA TEL (NOT SHOWN) ECO-00008543 1 ea 121711 B.01 BALANCE WEIGHT KIT, BASIC, MEDIUM (NOT SHOWN) ECO-00009762 SYSTEMS 40-300068 SEA TEL 6012-12, 12W Gilat,Single,76"...
  • Page 96 VER EC DESIGNER/ENGINEER: X.X = .050 K.D.H. UNLESS OTHERWISE SPECIFIED X.XX = .020 DIMENSIONS ARE IN INCHES. X.XXX = .005 WEIGHT: ANGLES: .5 MATERIAL: INSPECTION DIMENSIONS NOTED BY X.X SHALL HAVE FEATURE SIZE DIMENSIONS AND ASSOCIATED GD&T TOLERANCES INSPECTED FINISH: INTERPRET TOLERANCING PER ASME Y14.5 - 2009 SURFACE ROUGHNESS: 3rd ANGL...
  • Page 97 6012-12 Page 8 of 12 BOM Explosion Report Item Number: DL-000831-A Description: SYSTEM BLOCK LIST BOM, 6012-12 Item Revision: DCO-00013426 Date as of: 10/01/2015 09:14:52 AM PDT Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 92-148458-A DRAFTA SYSTEM BLOCK DAIGRAM, 6012-12 DCO-00013425...
  • Page 98 6012-12 Page 9 of 12 BOM Explosion Report Item Number: DL-000831-A Description: SYSTEM BLOCK LIST BOM, 6012-12 Item Revision: DCO-00013426 Date as of: 10/01/2015 09:14:52 AM PDT Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 37-148125-A CABLE ASSY, ICU TO NJRC SSPB BIAS TEE ECO-00014013 132956-1...
  • Page 99 6012-12 Page 10 of 12 BOM Explosion Report Item Number: DL-000831-A Description: SYSTEM BLOCK LIST BOM, 6012-12 Item Revision: DCO-00013426 Date as of: 10/01/2015 09:14:52 AM PDT Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 139034-1 A.01 ROTARY JOINT, WR-75, KU-NET ECO-00008547...
  • Page 100 6012-12 Page 11 of 12 BOM Explosion Report Item Number: DL-000831-A Description: SYSTEM BLOCK LIST BOM, 6012-12 Item Revision: DCO-00013426 Date as of: 10/01/2015 09:14:52 AM PDT Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 1 ea 135689-10 MCO-00015608 CONN,PHOENIX,PLUGBLE,TERM BLCK,5.08MM PITCH,10 POS...
  • Page 104 Page 2 of 2 BOM Explosion Report Item Number: 62-146645 Description: GENERAL ASSEMBLY, 6012-12 Item Revision: B.07 ECO-00017508 Date as of: 06/14/2016 11:07:07 AM PDT Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 97-146651-B DRAFTB ASSEMBLY DRAWING, GENERAL ASSEMBLY, DCO-00015055 6012-12 DL-000604-C A Software Assembly, General Release IMA...
  • Page 105 DETAIL A + - 1 1 2X DETAIL B DESIGNER/ENGINEER: X.X = .050 UNLESS OTHERWISE SPECIFIED X.XX = .020 DIMENSIONS ARE IN INCHES. X.XXX = .005 WEIGHT: 249.6 lbs ANGLES: INSPECTION DIMENSIONS NOTED BY X.X SHALL HAVE FEATURE SIZE MATERIAL: DIMENSIONS AND ASSOCIATED GD&T TOLERANCES INSPECTED FINISH:...
  • Page 107 6012-12 Page 7 of 12 BOM Explosion Report Item Number: 69-148597 Description: ICU MOUNTING ASSEMBLY, 6012 BASIC Item Revision: A.02 ECO-00015960 Date as of: 01/28/2016 02:23:44 PM PST Find Num Inventory Unit (LN6) Number Description / Title BOM Notes 97-148614-B DRAFTB ICU MOUNTING ASSY DWG, 6012 DCO-00015056...
  • Page 108 0001 58 59 4X 14 52 58 DESIGNER/ENGINEER: X.X = .050 K.D.H. UNLESS OTHERWISE SPECIFIED X.XX = .020 DIMENSIONS ARE IN INCHES. X.XXX = .005 WEIGHT: 13.482 LBS ANGLES: MATERIAL: INSPECTION DIMENSIONS NOTED BY X.X SHALL HAVE FEATURE SIZE DIMENSIONS AND ASSOCIATED GD&T TOLERANCES INSPECTED FINISH: INTERPRET TOLERANCING PER ASME Y14.5 - 2009...
  • Page 109 6012-12 Page 6 of 12 BOM Explosion Report Item Number: 62-146649 Description: MOUNTING ASSY, NJRC 8W, 6012 Item Revision: A.01 ECO-00015960 Date as of: 01/28/2016 02:23:44 PM PST Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 97-146650-B DRAFTB ASSEMBLY DRAWING, GILAT BUC MOUNTING, DCO-00015081 6012...
  • Page 110 0001 52 60 DESIGNER/ENGINEER: X.X = .050 UNLESS OTHERWISE SPECIFIED X.XX = .020 DIMENSIONS ARE IN INCHES. X.XXX = .005 WEIGHT: ANGLES: INSPECTION DIMENSIONS NOTED BY X.X SHALL HAVE FEATURE SIZE MATERIAL: DIMENSIONS AND ASSOCIATED GD&T TOLERANCES INSPECTED FINISH: INTERPRET TOLERANCING PER ASME Y14.5 - 2009 SURFACE ROUGHNESS: 3rd ANGL PROJECT...
  • Page 111 6012-12 Page 5 of 12 BOM Explosion Report Item Number: 62-148453 Description: ANTENNA INSTALL ASSY, 6012 KUNET TX/RX X-POL Item Revision: A.02 ECO-00015922 Date as of: 01/26/2016 07:32:17 AM PST Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 97-148474-A DRAFTA ANTENNA INSTALL ASSY, 6012 KUNET TX/RX...
  • Page 112 REV EC 50 51 DESIGNER/ENGINEER: X.X = .050 UNLESS OTHERWISE SPECIFIED X.XX = .020 DIMENSIONS ARE IN INCHES. X.XXX = .005 WEIGHT: ANGLES: MATERIAL: INSPECTION DIMENSIONS NOTED BY X.X SHALL HAVE FEATURE SIZE DIMENSIONS AND ASSOCIATED GD&T TOLERANCES INSPECTED FINISH: INTERPRET TOLERANCING PER ASME Y14.5 - 2009 SURFACE ROUGHNESS: 3rd ANGL...
  • Page 113 6012-12 Page 4 of 12 BOM Explosion Report Item Number: 62-148767 Description: KIT, WAVEGUIDE, 6012-XX Item Revision: A.01 MCO-00024016 Date as of: 04/22/2016 01:11:35 PM PDT Find Num Qty Inventory Unit (LN6) Number Description / Title BOM Notes 97-148768-A DRAFTA KIT, WAVEGUIDE, 6012-XX DCO-00013703 41-148743-A 04...
  • Page 114 DESIGNER/ENGINEER: X.X = .050 K.D.H. UNLESS OTHERWISE SPECIFIED X.XX = .020 DIMENSIONS ARE IN INCHES. X.XXX = .005 WEIGHT: 0.5 lbs ANGLES: MATERIAL: INSPECTION DIMENSIONS NOTED BY X.X SHALL HAVE FEATURE SIZE DIMENSIONS AND ASSOCIATED GD&T TOLERANCES INSPECTED FINISH: INTERPRET TOLERANCING PER ASME Y14.5 - 2009 SURFACE ROUGHNESS: 3rd ANGL PROJECT...
  • Page 115 Page 1 of 2 BOM Explosion Report Item Number: 62-150347 Description: BALLANCE WEIGHT KIT CL & EL, 6012-12 Item Revision: ECO-00016030 Date as of: 02/04/2016 02:34:38 PM PST Find Num Inventory Unit (LN6) Number Description / Title BOM Notes 97-150349-A DRAFTA BALLANCE WEIGHT KIT CL &...
  • Page 116 58 59 59 2X...
  • Page 117 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 128652-1 A2 RADOME TOP FAB, 76 IN, WHITE 1 EA 130395-1 A3 RADOME BASE ASS'Y, 76 IN, WHITE 1 EA 130390-2 KIT, HARDWARE, GA TO RADOME, RAISED 1 EA 130394-2 KIT, HARDWARE, RADOME TO MAST, 12-HOL 4 EA 119801-012...
  • Page 118 REV EC PARTS OF THE FULL ASS'Y HARDWARE SHOWN ARE OMITTED FOR CLARITY IS FOR TRANSIT ONLY. REMOVE AND REPLACE WITH KIT 130394-2 AT FINAL INSTALLATION. DESIGNER/ENGINEER: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. X.X = .050 WEIGHT: X.XX = .020 X.XXX = .005...
  • Page 119 SEE SECTION B-B (BOW) Towards Hatch Door (AFT) 53 54 8 54 64 SEE DETAIL D 54 9 SEE DETAIL MOUNT INDICATED ITEMS IN APPROXIMATE LOCATIONS AS SHOWN (PARTIAL GENERAL ASSEMBLY SHOWN FOR REFERENCE ONLY)
  • Page 121 Purpose. To define the installation procedure for installing strain reliefs in “smooth base” radomes. Scope. This installation procedure applies to fiberglass radomes having Sea Tel’s standard four-hole mounting pattern, and M12 mounting hardware, in the 80-180 cm (34-66 in) nominal size range, typically referred to as “smooth” base radomes. It also applies to our larger 193 cm (76-inch) radome having a twelve-hole mounting pattern.
  • Page 122 Procedure, Radome Strain Relief Installation Making the holes PLANNING: Space has been allowed for up to 5 ea. strain reliefs, but, install only as many as needed. (Typically only 2-3 TX/RX systems). Refer to Fig 2 then plan which hole positions to use. For 76-inch radomes lowest holes may be approx 1.5 inches from inside wall corner with floor (ref drawing 129416).
  • Page 123 Procedure, Radome Strain Relief Installation Measure, mark and drill pilot holes CAUTION: The hole locations cannot be determined accurately from outside of the radome. Using full scale drawing 132234, provided in the strain relief kit, measure mark and drill pilot holes from the inside out, and using only light pressure, use the small drill bit, (~1/8”...
  • Page 124 Procedure, Radome Strain Relief Installation Fig. 5 – Outside view. Rotate General Assembly (G.A.) Once cables have been installed, rotate General Assembly (G.A.), to ensure cables are routed properly and do not interfere with azimuth rotation. Fig. 6 – Inside view. Records.
  • Page 125 Procedure, Radome Strain Relief Installation Strain relief positioning for 80-180 cm (34-66 in) smooth based radomes, (May use Sea Tel drawing 132234 as template.) Document No Page 5 of 6 131226 Rev A Form # 117140-B...
  • Page 126 Procedure, Radome Strain Relief Installation Strain relief positioning for 193 cm (76-inch) radomes. (May use Sea Tel drawing 132234 as template.) Document No Page 6 of 6 131226 Rev A Form # 117140-B...
  • Page 127 SINGLE LEVEL MFG BILL OF MATERIAL FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR 1 EA 138633-4 BDE CABLE KIT, 4012GX (MXP) 1 EA 136872 A1 BRACKET ASS'Y, CONNECTOR, RACK MOUNT 1 EA 139410 BOX, ACCESSORY BELOW DECK KIT, MXP PROD FAMILY EFF.

Table of Contents
