Table 6: Summary of Spanning Tree Protocols Output Fields (continued)
Field
Designated Bridge ID
Port Cost
Port State
Role
Spanning Tree Statistics of Interface
Interface
BPDUs Sent
BPDUs Received
Next BPDU Transmission
Related
Documentation
Copyright © 2017, Juniper Networks, Inc.
Values
ID of the designated bridge to which the interface is attached.
Configured cost for the interface.
Spanning-tree protocol port state:
Forwarding (FWD)
Blocking (BLK)
Listening
Learning
Disabled
MSTP or RSTP port role, Designated (DESG), backup (BKUP), alternate (ALT),
or root.
Interface for which statistics is being displayed.
Total number of BPDUs sent.
Total number of BPDUs received.
Number of seconds until the next BPDU is scheduled to be sent.
show spanning-tree interface
show spanning-tree bridge
Configuring Spanning Tree Protocols (J-Web Procedure) on page 28
Chapter 3: RSTP Monitoring Commands
