Dimensions - Danfoss VLT 2010 Manual

®
VLT Series 2000
VLT 2010-2030
Single-phase, 220-240 V
Three-phase, 208-240 V
NOTE:
Minimum space above and below the unit is 4 inches.
Minimum space to the sides of the unit is 0 inches.
VLT 2010-2030 with module
Single-phase, 220-240 V
Three-phase, 208-240 V
NOTE:
Minimum space above and below the unit is 4 inches.
Minimum space to the sides of the unit is 0 inches.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Installation; Dimensions
4.3
(110)
3.5
(90)
7.1
(180)
9.3
(235)
10.2
(260)
4.3
(110)
3.5
(90)
7.1
(180)
14.3
(338)
14.3
(363)
0.21
(5.5)
0.29
(7.5)
0.43
(11)
0.21
(5.5)
0.17
(4.5)
0.21
(5.5)
0.29
(7.5)
0.43
(11)
0.21
(5.5)
0.17
(4.5)
5
