Operation
Programming Keys
is used to enter MENU MODE from either DATA
Menu
MODE or DISPLAY MODE. MENU is also used for entering
a specific group of parameters.
is used for entering DATA MODE or DISPLAY
Data
MODE from MENU MODE. DATA is also used to move the
cursor in data values.
Operator Keys
Four keys are provided for local control:
Stop
Start
Reset
With theexception of the Start key the keys can be
programmed to be enabled or disabled to prevent unwanted
use in certain applications.
Operational Modes
The VLT will be in DISPLAY MODE when the motor is
running in normal operation. DISPLAY MODE provides
various information concerning the current status of the VLT
and motor.
+
–
The and
the 12 main display readouts:
• Reference
• Frequency Hz
• Display Feedback unit
• Current A
• Torque %
• Power kW
• Power HP
• Energy kWH
• Output voltage V
• DC voltage V
• Motor ETR value %
• Inverter ETR value %
