Appendix C: Electromagnetic Compatibility
C.2 Manufacturer's Guidance and Declaration – Electromagnetic
Immunity
The Corometrics TM 250cx Series Maternal/Fetal Monitor is intended for use in the electromagnetic environment
specified below. It is the responsibility of the customer or user to enssure that the monitor unit is used in such
an environment.
Immunity Test EN60601 Test Leve
Electromagnetic ± 6 kV contact
Discharge (ESD) EN
61000-4-2
± 8 kV air
Electrical Fast ± 2 kV for power supply lines
Transient/Burst
EN 61000-4-4
±1 kV for input/output lines
Surge ± 1 kV differential mode
EN 61000-4-5
± 2 kV common mode
<5% U
cycles
Voltage dips, short
<40% U
interruptions and
cycles
voltage variations
on power supply
input lines EN
<70% U
61000-4-11
cycles
<5% U
Power Frequency 3 A/m
(50/60 Hz) Magnetic
Field EN 61000-4-8
NOTE: U is the AC mains voltage prior to application of the test level.
t
144
(>95% dip in Ut) for 0.5
t
(>60% dip in U )for 5
t t
(>30% dip in U )for 25
t t
(>95% dip in U )for 5 s
t t
2036947-001
Compliance Level
± 6 kV contact
± 8 kV air
± 2 kV for power supply lines
±1 kV for input/output lines
± 1 kV differential mode
± 2 kV common mode
<5% U (>95% dip in U ) for 0.5
t t
cycles
<40% U (>60% dip in U ) for 5
t t
cycles
<70% U (>30% dip in U ) for 25
t t
cycles
<5% U (>95% dip in U ) for 5 s
t t
3 A/m
© 2013 by General Electric Company. All rights reserved.
Electromagnetic
Environment – Guidance
Floors should be wood, concrete
or ceramic tile. If floors are
covered with synthetic material,
the relative air humidity should
be at least 30%.
Mains power should be that of
a typical commercial or hospital
environment.
Mains power should be that of
a typical commercial or hospital
environment.
Mains power should be that of
a typical commercial or hospital
environment. If the user of the
equipment requires continued
operation during power mains
interruptions, it is recommended
that the equipment be powered
from an uninterruptible power
supply or a battery.
Power frequency magnetic
fields should be at levels
characteristics of a typical
location in a typical commercial
or hospital environment.
