Rear Panel
Setting up
The QTFX-400P requires fog fluid to produce the fog effect.
We recommend QTX Standard (1l: 160.643UK, 5l: 160.582UK) or High Grade (1l: 160.587UK,
5l:160.588UK) fog fluid for use with this machine.
Unscrew the top cap of the tank and remove to fill with the selected fog fluid
•
Replace the cap and close securely, ensuring the pipe is fed down to the bottom of the
•
bottle so a consistent flow of fluid is supplied to the machine
Connect the IEC mains plug
•
Operation
Check to make sure there is sufficient fog fluid in the reservoir
•
Switch the mains power on.
•
Heat up time is usually between 4-5 minutes. Please ensure that the control button is
•
not pressed during the heat up time.
When the machine is ready to operate, the green light on the control will illuminate.
•
You may now press the button for fog on demand.
When the control red light is on, the machine needs time to re-heat. Do not attempt to
•
produce fog until the green light is lit.
During prolonged use, periodically check that the fluid level is not empty.
•
Switch off when not in use. Unplug from mains if not in use for long periods.
•
1. Mains power on/off switch
2. Hard wired controller connection
3. IEC input and fuse holder
