Appendix E: Technical Data
E Technical Data
General
Model name
Order code
Dimensions (L x W x H)
Operating temperature
Storage temperature
Humidity range
Mechanical rating
Mounting
Power supply
Terminal wiring
Certifications
Communication
Interface Ethernet Port
Compliance IEEE 802.3
Protocols Modbus TCP,
BACnet/IP
Data rate 10/100 Mbit/s
Physical layer 10BASE-T,
100BASE-TX
Maximum 100 m
cable length
Port connector Shielded RJ-45
Isolation 1500 VDC
BACnet
Order Code
Maximum number of BACnet Objects
Maximum number of BACnet Subscriptions (COV) request:
Supported BACnet device types
Supported Modbus slave device types
Maximum number of Modbus Slave devices
Modbus to BACnet Gateway User Manual
Anybus Modbus to BACnet Gateway
AB9900-nnnn (nnnn = number of datapoints)
90 x 88 x 56 mm
0 to +60 °C
-40 to +85 °C
5 to 95 % non-condensing
IP20
DIN rail or screw mount
Must be NEC Class 2 or LPS and SELV rated
AC: 24 VAC ±10 %, max. 127 mA
DC: 9 to 36 VDC ±10 %, max. 140 mA
(Recommended: 24 VDC)
Use solid or stranded wires (twisted or with ferrule)
1 core: 0.5 to 2.5 mm 2
2 cores: 0.5 to 1.5 mm 2
3 cores: not permitted
CE and RoHS compliant, BTL certification
See www.anybus.com/support
EIA-485 (Port A)
Modbus V1.02
Modbus RTU
2.4, 4.8, 9.6, 19.2, 38.4, 57.6, 115.2 kbps
EIA-485, 3-wire isolated
2.4 to 57.6 kbps: 1200 m
115.2 kbps: 1000 m
2 x 2-pin pluggable terminal blocks
1500 VDC
for more information.
EIA-485 (Port B)
BACnet Rev 12
BACnet MS/TP
Auto, 9.6, 19.2, 38.4, 57.6, 76.8, 115.2 kbps
EIA-485, 3-wire isolated
2.4 to 76.8 kbps: 1200 m
115.2 kbps: 1000 m
3-pin pluggable terminal block
1500 VDC (except from D-sub connector)
AB9900 – 100 250
100 250
200 500
IP, MSTP
Modbus RTU (EIA485), Modbus TCP
Up to 255 devices per node (RTU and TCP)
Up to 5 TCP connections
55 (56)
600 1200 3000
600 1200 3000
1200 2400 6000
SCM-1202-049 1.0
