Installation
4.5
Connecting the Power Supply
Connect a suitable power supply to the Power terminal. See
the power supply requirements.
4.6
Configuration Connections
Connect the computer to be used for configuration to the Console port on the front panel of the
gateway using a standard USB type B cable.
The gateway can also communicate with the computer over Ethernet if they are connected to
the same Ethernet network subnet. The gateway uses DHCP as default.
The USB port next to the EIA-232 serial port is only intended for making file backups to a USB
flash drive and cannot be used for configuration.
Modbus to BACnet Gateway User Manual
Observe the correct polarity of the connections, see
Technical Data, p. 55
regarding
Connectors, p.
8.
SCM-1202-049 1.0
12 (56)
