Anybus AB7702 Installation Manual

Confi guration
Anybus IPconfi g utility
The Anybus IPconfi g utility is a Windows-based confi guration utility to set TCP/IP network settings in Anybus devices. It scans
the Ethernet network for connected devices and allows the user to set the IP address, netmask, default gateway, DNS and
hostname for each unit.

Installation Procedure

1. Go to http://www.anybus.com/products/abxss.shtml
2. Download and install the IPconfi g package.

Scanning for connected devices

First ensure that you have connected the Anybus units you want to install on the same Ethernet network the PC is connected
to. Use standard Ethernet cables, straight-through or cross-over cables depending on how you connect to the device.
When IPconfi g is started, it will scan the Ethernet network for Anybus devices. All detected devices will be presented in a list in
the main window. To refresh the list, click on Scan.

Changing IP settings

To change the IP settings on a detected device, double-click the device in the list of devices. This will open up a dialog in
which you can enter the desired IP confi guration. The default password for authentication of the new settings is "admin".
Click Set to restart the Anybus device with the new settings applied.
Test the new settings by opening a web browser and entering the assigned IP address. To discover the assigned IP address
when using DHCP, simply perform a new scan with the IPconfi g utility and locate the device in the list.

Technical data

Power Supply: 9–24 V AC/DC (2W)
Temperature range: Operating: -40 to +65 °C
Storage: -40 to +85 °C
Humidity range: 5–95 % RH, non-condensing
Mounting option: DIN rail (EN 50022)
CE certifi cation: According to EN 55011:2007 and EN 61000-6-2:2005
SP1668, rev. 3.1, Apr 2016 AB7702-B
and select File/Document Downloads.
!
Do not enable DHCP if there is no available
DHCP server on the network.
E214107
®
Anybus Modbus-TCP/RTU Gateway
HMS Industrial Networks
Mailing address: Box 4126, 300 04 Halmstad, Sweden
Visiting address: Stationsgatan 37, Halmstad, Sweden

INSTALLATION GUIDE

SP1668 3.1
